Full-Color LED Display Controller User Manual
Full-Color LED Display Controller User Manual Legal Information ©2020 Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved. About this Manual The Manual includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
Full-Color LED Display Controller User Manual INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
Full-Color LED Display Controller User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
Full-Color LED Display Controller User Manual Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (A)/NMB-3(A) standards requirements.
Full-Color LED Display Controller User Manual Preface Applicable Models This guide is applicable to full-color LED display controller. Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Danger Indicates a hazardous situation which, if not avoided, will or could result in death or serious injury.
Full-Color LED Display Controller User Manual Contents Chapter 1 Product Introduction .................................................................................................. 1 1.1 Overview ................................................................................................................................ 1 1.2 Main Features ........................................................................................................................ 1 1.3 Physical Interface ................
Full-Color LED Display Controller User Manual 3.11 Configure On/off Image ..................................................................................................... 23 3.12 Configure Multicast Control ............................................................................................... 23 3.13 Configure Video Window Opening .................................................................................... 24 3.14 Configure Screen Splicing ..............................................
Full-Color LED Display Controller User Manual 7.1 Full Screen is Unlit ................................................................................................................ 38 7.2 Image is Incomplete or in Wrong Position ........................................................................... 38 7.3 Full-screen Image Flashes or Vibrates .................................................................................. 39 7.4 Spots/Strips Exist in Full-screen Image .............................
Full-Color LED Display Controller User Manual Chapter 1 Product Introduction 1.1 Overview LED Full-Color Display Controller can be used with the full-color display units to achieve the seamless jointing of the video wall in any dimensions. It is applicable to the meeting rooms, studio, gym, airport, bank, advertisement, family cinema, etc. 1.
Full-Color LED Display Controller User Manual Powerful System Functions • DVI, DP, and 2 HDMI signal source input, and HDMI loop output available • HD signal input at up to 4096 × 2160@60 Hz (4K) and 4K point-to-point output • Image scaling available 1.
Full-Color LED Display Controller User Manual Indicator Description Indicator Description BACK • Long press: unlock the menu SOURCE/ lock and press the knob to TEST enter menu mode • Short press: back to the previous menu or the main menu • Long press: enter the image test mode • Short press: switch the signal source POWER UP/ DOWN • Long press: device in sleep • Short press: awake the device —— —— Rear Panel Figure 1-2 Rear Panel Interface Table 1-2 Interface Description of Rear Panel Interface
Full-Color LED Display Controller User Manual Chapter 2 Device Activation and Login 2.1 Activate the Device In order to protect personal account privacy and reinforce system/data security, you need to set login password and activate the device for your first login. Before You Start • The client software has been installed correctly. • PC and the device are in the same network segment. Steps 1. Run the client . Figure 2-1 Register 2.
Full-Color LED Display Controller User Manual Figure 2-2 Activate Online Device 3. Select the device to be activated and click Activate. 4. Enter Password and Confirm Password in the popup window. Figure 2-3 Activation Caution We highly recommend you create a strong password of your own choosing (Using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers, and special characters.) in order to increase the security of your product.
Full-Color LED Display Controller User Manual Note If the network segment which device connected has DHCP function, it will allocate IP by default, please skip step 6, 7 and 8. 2.2 Add Power Distribution Cabinet You can add a power distribution cabinet as needed. The client can turn on/off the screen remotely after adding the power distribution cabinet. Steps 1. Double click LED Display Controller to run the client. 2. Click Power Distribution Cabinet Config. Figure 2-4 Login 3. Enter IP and port No.
Full-Color LED Display Controller User Manual Chapter 3 Client Configuration and Operation 3.1 Wizard For the first login, the client will pop up a wizard, including display attribute configuration and signal cable configuration. Set the parameters as needed, and the client can recognize the screen parameters automatically when you log in the next time. 3.1.
Full-Color LED Display Controller User Manual Save parameters in the receiving card to ensure your screen displays properly after next reboot. Configure Screen Resolution After configuring the screen resolution, the display image can match the actual screen resolution. It can reduce the image loss and partial black screen caused by resolution. Steps 1. Enter Display Attribute interface. 2. Check Signal Resource Zoom. 3. Select Screen Resolution. - Select resolution in Screen Resolution.
Full-Color LED Display Controller User Manual Figure 3-2 Signal Cable Configuration 4. Connect signal line. - Click the screen on the right side of the interface to connect signal line. - Select Line Type, and select starting port and end port on the right side of the interface. 5. Right-click on the right side of the interface after connection. 6. Select Complete Signal Cable Connection. 7. Click Save. Port configuration information set. will pop up after the signal cable is connected.
Full-Color LED Display Controller User Manual Port of sending card is applied to communicate between sending card and receiving card. The receiving card connected by signal sending port is Card1, the receiving card connected to the first sending card is Card2, and so on. Cancel Cancel last operation. Restore Resume last operation. Reset Current Port Cancel all settings of current signal sending port. Reset All Ports Cancel settings of all signal sending ports.
Full-Color LED Display Controller User Manual Steps 1. Click Screen Adjustment → Advanced Operation → Correction → Manual Correction . Figure 3-3 Correct Screen Manually 2. Select Enable Correction. 3. Select Screen in Correction. Drag the bar of Minimum Effective Correction Value and the data bigger than the set value can be corrected. 4. Select area to correct. - Check Show Module and select the module to correct. - Uncheck Show Module and select the screen to correct. 5.
Full-Color LED Display Controller User Manual Figure 3-4 Correct the Whole Screen - Correct the selected area of the screen: click coordinate of the desired area. , and input the start coordinate and end Figure 3-5 Correct the Area of the Screen 6. Adjust RGB value. - Drag the bars. - Enter numbers in the text boxes. Note • You can check Simultaneous Adjustment to adjust RGB simultaneously. • The number ranges from 800 to 1200, and the default value is 1000.
Full-Color LED Display Controller User Manual 7. Click Preview or press Enter to check the effects. 8. Click Apply. Operation Description Clear Reset all parameters if needed. Load Original Data Load original correction data. Note The function may vary with models. The parameters will not be displayed when the function not supported. Correct Seam Manually Steps 1. Click Screen Adjustment → Advanced Operation → Correction → Manual Correction . Figure 3-6 Correct Seam Manually 2.
Full-Color LED Display Controller User Manual Horizontal Line Correct all horizontal seams. 5. Select area to correct. - Check Show Module and select the module to correct. - Uncheck Show Module and select the screen to correct. 6. Drag the bar to adjust Seam Width. Note The seam width ranges from 1 to 10. 7. Adjust RGB value. - Drag the bars. - Enter numbers in the text boxes. Note • You can check Simultaneous Adjustment to adjust RGB simultaneously.
Full-Color LED Display Controller User Manual DownLoad Download the correction file as the backup files. You can also upload this correction file to correct other devices. 3.3.2 Configure Screen Color You can adjust color temperature and color standard as needed. Before You Start Connect the signal source to the device before configuring the image contrast and saturation. Steps 1. Go to Screen Adjustment → Basic Control → Image Adjustment . Figure 3-8 Image Adjustment 2. Select Color Temperature . 3.
Full-Color LED Display Controller User Manual 3.3.3 Configure Brightness Configure LED screen brightness. Steps 1. Click Screen Adjustment → Basic Control → Basic Configuration . Figure 3-9 Brightness Adjustment 2. Adjust the brightness. Brightness ranges from 1 to 8. Brightness of energy saving mode ranges from 1 to 2. Brightness of balanced mode ranges from 3 to 4. Brightness of high light mode ranges from 5 to 6. Brightness of sport mode is from 7 to 8. - Slide the slider.
Full-Color LED Display Controller User Manual Steps 1. Go to Screen Adjustment → Basic Control → Image Enhancement . Figure 3-10 Image Enhancement 2. Select Scene Enhancement or slide the slider to adjust Clarity, Contrast and Saturation. Sunlight Scene When the device is in well-lit environment, you can select it and the corresponding strength. Darkness Scene When the device is not in well-lit environment, you can select it and the corresponding strength. 3.
Full-Color LED Display Controller User Manual Note • Before enabling 3D Video Processing, you need to install mulch-functional card first. • Only when 3D parameters are configured into screens, 3D Video Processing can be enabled. • After enable 3D Video Processing, 3D Processing Mode and Left-Right Image Switch can be supported. 3D Processing Mode 3D Processing Mode is divided into Left-Right Alternating, Left-Right Image Integration and Upper-Lower Image Integration.
Full-Color LED Display Controller User Manual Steps 1. Go to Screen Adjustment → Basic Control → Basic Configuration . 2. Slide the slider or enter numbers in the text box to adjust the volume. 3.5 Configure a Scene You can save the configurations of, for example, signal input type, 3D video processing, or video opening window, as a scene to call for convenience. Steps 1. Click Scene on the right of the interface. Figure 3-12 Scene Configuration 2. 3. 4. 5. Click . Enter a scene name.
Full-Color LED Display Controller User Manual Operation Description Call the scene. Apply the scene. 3.6 Add Device Alias Device alias is used to distinguish devices from each other. Steps 1. Click on the Display Status. 2. Edit device alias. 3. Click OK to save the device alias. 3.7 Configure Message Release rolling/static meaasge to terminal by the client. Before You Start No-signal screensaver is in custom mode. Refer to Configure No-Signal Screensaver . Steps 1.
Full-Color LED Display Controller User Manual Note Background color is black by default and is not adjustable. 5. Click Apply. 3.8 Configure OSD Screen will display prompts after configuring OSD (On-screen Display). Steps 1. Click Screen Adjustment → Advanced Operation → OSD Configuration . Figure 3-14 OSD Configuration 2. Click Enable OSD. 3. Configure OSD Text and OSD Background Color. 4. Click Apply. Operation Configuration Restore Default Settings Restore to default OSD settings. 3.
Full-Color LED Display Controller User Manual 3.10 Configure No-Signal Screensaver The screen will display default no-signal screensaver when there is week input signal or no input signal. Steps Note You can choose default mode, custom mode, and black screen mode. Here we take custom mode as an example. 1. Click Screen Adjustment → Basic Control → No-Signal Screensaver . Figure 3-15 No-Signal Screensaver Configuration 2. Click Custom. 3. Click Select Picture to select the pictures. 4. Click Upload.
Full-Color LED Display Controller User Manual 3.11 Configure On/off Image You can use the screen saver as the on/off image or customize the image. Take customizing the on/off image as an example. Steps 1. Click Screen Adjustment → Advanced Operation → On/Off Image . Figure 3-16 On/Off Image Configuration 2. Click Custom, and click Select Image to select an image in your computer. 3. Click Upload. Note Only images in JPG format with resolution from 320 × 240 to 3840 × 3840 are available. 3.
Full-Color LED Display Controller User Manual Note Items available for multicast control include brightness/white balance, signal input switch, dehumidification configuration, attribute configuration, system configuration, basic configuration, and advanced configuration. Check the items based on your needs. 3. Check the device you want to synchronize. 4. Click OK. Note You can login to any checked IP to achieve multicast control. 3.
Full-Color LED Display Controller User Manual Default The area displays the defalut picture in the system. Black Screen The area displays black screen. Custom Click Upload to upload pictures to be displayed. You can also replace or delete the uploaded pictures. Please upload pictures in JPEG or JPG format with size smaller than 6 MB. 5. Click OK. 3.
Full-Color LED Display Controller User Manual • • • • Note Only horizontally screen splicing is supported. Please enter the user name and password for the first time login of the device. If you want to splice a new device, click before the binded device first, and then click before the desired device. If the binded device is offline, the splicing area will turns grey. 4. Click OK. 5. Optional: You can click Clear the Binded to clear all the binded devices.
Full-Color LED Display Controller User Manual Chapter 4 Device Maintenance 4.1 Screen Defective Pixel Detection You can check the defective pixels of the screen. You can hover over the virtual screen on Display Status to check the number of defective pixels on the screen. Table 4-1 Defective Pixel Detection Icon Description Show the position of defective pixels on the display. Show the coordinates of the defective pixels on the client. 4.
Full-Color LED Display Controller User Manual 2. Select Enable Detection. 3. Select the image you want to test. - Click the image you want to test. - Click the white box beside Custom Color to customize colors, and click OK. - Click Enable Auto Detection, and the system will display default images to test. 4.3 Configure Advanced Image You can configure the level and brightness level of the original grayscale to improve the image quality. Steps 1.
Full-Color LED Display Controller User Manual Figure 4-3 Dehumidification Configuration 2. Select Auto Dehumidification. 3. Select Area. High Humidity Area, Medium Humidity Area, Low Humidity Area are selectable. 4. Click OK. Operation Description Enable Dehumidification Enable dehumidification manually. Disable Dehumidification Disable dehumidification manually. Note Disable dehumidification manually is valid for single time. Dehumidification function will be auto enabled after next startup. 4.
Full-Color LED Display Controller User Manual Energy-Saving Mode The brightness is level 3 by default and level 3 at most. Normal contrast. Original grayscale is level 0. Low refresh rate. HDR Mode The brightness is level 10 by default and level 10 at most. High contrast. Original grayscale is level 1. High refresh rate. Note • The Normal Mode is recommended to prevent overheat caused by high consumption. • When the system is restored to default or factory settings, the work mode is Normal Mode by default.
Full-Color LED Display Controller User Manual Figure 4-4 Receiving Card Version 2. Check receiving card details in the receiving card version interface for device maintenance. 3. Click OK. 4.9 Upgrade Please use the latest firmware to obtain all possible security updates. Note Do not disconnect the power supply during updating. 4.9.1 Local Upgrade Upgrade Receiving Card/Multi-functional Card You can upload upgrade patch to upgrade receiving card or multi-functional card.
Full-Color LED Display Controller User Manual Steps 1. Click System Settings → System Maintenance → Upgrade 2. Click to select upgrade patch. 3. Click Upgrade. Operation Description Auto Update Receiving Card Version When Rebooting When sending card reboots, it will detect receiving card version. System will update receiving card version by default if there is a new version. Note If upgrading failed and the device cannot function correctly, please contact suppliers in time.
Full-Color LED Display Controller User Manual 2. Click on the right side of Receiving Card Version, the device will automatically get the newest version of the upgrade package from the cloud. Note • If the receiving card is the newest version already, there is no need to upgrade. • The receiving card will automatically restart when upgraded. Upgrade Sending Card Online Get the newest version of the upgrade package from the cloud to upgrade the sending card.
Full-Color LED Display Controller User Manual Chapter 5 System Maintenance This chapter mainly introduces importing/exporting configuration file, searching logs, restoring parameters, restoring default settings, and time synchronization. 5.1 Import/Export Configuration File Configuration file can be imported to configure the system easily. Steps 1. Click System Settings → System Maintenance → Import and Export . 2. Click to select file path. 3. Click Import. 5.
Full-Color LED Display Controller User Manual 4. Optional: Click Export to export all the search results. Note Logs can be exported in CSV or XML file format. A prompt window will pop up when the logs are exported successfully. 5.4 Sync Time Steps 1. Click System Settings → System Maintenance → Sync Time . 2. Set time synchronization mode. - Select Local Time to synchronize the device time with the client. - Click , setting display time manually, and click OK. 3. Click Time Sync. 5.
Full-Color LED Display Controller User Manual Chapter 6 Local Configuration and Operation Use a combination of multi-functional card and remote control to operate the LED screen OSD menu. Ensure the device is connected and activated before using the remote control. Press Menu button to go to Local Operation. You can configure the parameters of input, output, image, system, sending card and receiving card in Local Operation. 6.
Full-Color LED Display Controller User Manual Key Description Shortcut Press the shortcut key and press the number key to enable function quickly. Press the back key to disable the function. • 0: Enable 3D function. • 1: Enable dehumidification. • 2: Enable image enhancement. • 3: Enable image correction. • 4: Enable auto-adaptive resolution. • 5: Enable auto-switch screensaver. • 6: Enable screen self-checking. Help Help ID Select the desired screen(s).
Full-Color LED Display Controller User Manual Chapter 7 FAQ 7.1 Full Screen is Unlit Reason • • • • No power supply for screen or control device. No input signal. The controlling computer is sleeping or the graphics card settings are incorrect. Incorrect receiving card configuration. Solution • Check if the computer is in sleep or screensaver mode.
Full-Color LED Display Controller User Manual 7.3 Full-screen Image Flashes or Vibrates Reason • DVI output of graphics card or other device fails. • Receiving card number loaded by single network interface is larger than its load capacity. • Signal cable is too long. Solution • Check system connection to see if the DVI cable or the network cable is loose, if the signal cable length exceeds the allowable transmission distance, etc. • Reduce receiving card loading number of each network interface.
Full-Color LED Display Controller User Manual Solution • Check if the power supply output of the unit is 5 VDC. • Check if power supply indicator of the receiving card in the unit is solid red, or if the receiving card is operating normally. • Check the receiving card, HUB card, and data cable connection in the unit. • Check if the receiving card signal output of the previous unit is normal. 7.
