Powerful System Funcons
• DVI, DP, and 2 HDMI signal source input, and HDMI loop output available
• HD signal input at up to 4096 × 2160@60 Hz (4K) and 4K point-to-point output
• Image scaling available
1.3 Physical Interface
Front Panel
Figure 1-1 Front Panel Interface
Table 1-1 Interface Descripon of Front Panel
Indicator Descripon Indicator Descripon
POWER Power indicator
• Red: be in the sleep mode
• Green: work normally
ACTIVE Acve status indicator
Flickers green when the device
is powered on
SOURCE Signal source status indicator
• Steady on: with signal source
input
• Unlit: no signal source input
USB USB indicator
• Steady on: with USB inserted
• Unlit: no USB inserted
SYSERR System error indicator
Steady on green when system
error occurs
LINKERR Link error indicator
Steady on green when the
receiving card is oine
LCD Panel Display informaons such as
brightness, device IP, input/
output resoluon, signal source
type, menu lock status
Knob • Normal Mode (not the Menu
Mode): rotate right/le to
adjust brightness
• Menu Mode: rotate
right/le
to select menu item; press to
select or enter next menu
