Steps
1. Click Screen Adjustment → Advanced
Operaon → Correcon → Manual Correcon .
Figure 3-3 Correct Screen Manually
2. Select Enable Correcon.
3. Select Screen in
Correcon. Drag the bar of Minimum Eecve Correcon Value and the data
bigger than the set value can be corrected.
4. Select area to correct.
-
Check Show Module and select the module to correct.
-
Uncheck Show Module and select the screen to correct.
5. Correct the whole screen or correct the selected area of the screen.
-
Correct the whole screen: click , and select the desired screen.
