Quick Start Guide

5
1 Product Introduction
1.1 Introduction
Body camera (hereinafter referred to as device) highly
integrates with record, local storage, GPS, etc. It is
embedded with positioning module with high sensitivity
and ultra-low consumption, locating the occurring positon
of events accurately. It can record the process and
condition of events completely via recorded video and
audio. You can also tag the important data for future
search.
It is small and light, convenient to carry, and can be worn
on the shoulder, satisfying the requirement of mobile
duty and evidence record for single person. It is widely
applicable to public security protection, city
management, industry and commerce, etc.
1.2 Key Feature
 Full HD record.
 Supports GPS, and the position information can be
uploaded to the command center in real time.
 Supports IR night vision. Even in low illumination
condition, the facial characteristics in recorded video
are clear.
 Waterproof, dustproof, and fall protection, adaptable to
all-weather field operation.
 Wi-Fi accessible.
The functions vary with different models. The actual
product prevails.
1.3 Apperance
The device appearance is shown as Figure 1-1.
Figure 1-1 Appearance
The appearance description is shown as Table 1-1.
Appearance Description
No.
Name
Description
1
Mute button
 After the device starts up,
hold it to enable mute
mode. Then indicators, LED
light, IR light, and vibration
will be disabled.
 In mute mode, hold it to
disable mute mode.
