User's Manual

camera A controls the internal indicator B, the external indicator 2 of parking camera A, and the
external indicator 2 of parking camera B, and detects the status of the parking spaces B1 to B3. The
parking camera B controls the internal indicator A, the external indicator 1 of parking camera A,
and the external indicator 1 of parking camera B, and detects the status of the parking spaces A1 to
A3, as shown below. Aer the sengs, the external indicator 2 of parking camera A will display the
dierent status of parking space B1, the internal indicator B will display the dierent status of
parking space B2, and the external indicator 2 of parking camera B will display the dierent status
of parking space B3. The external indicator 1 of parking camera A will display the dierent status of
parking space A1, the internal indicator A will display the dierent status of parking space A2, and
the external indicator 1 of parking camera B will display the dierent status of parking space A3.
Figure 5-6 Internal and External Indicator Applicaon
5.4.3 Alternate Indicator Control Applicaon
Note
Here we take example of the scene in which two devices monitor six parking spaces.
The alternate indicator control is applicable to the parking lot where there are symmetric parking
spaces on both sides, and the dis
tance between the device to the monitored parking space lines is
too far.
E.g., the parking camera A controls the indicator B and detects the status of the parking spaces B1
to B3, while the parking camera B controls the indicator A and detects the status of the parking
spaces A1 to A3, as shown below. Aer the sengs, the indicator A/B will display the color of
