INSTRUCTION MANUAL BEDIENUNGSANLEITUNG MANUAL INSTRCUTIUNI РЪКОВОДСТВО ЗА ЕКСПЛОАТАЦИЯ UPUTE ZA UPORABU UPUTSTVO ZA UPOTREBU PRIRUČNIK FLAT DIGITAL TV DIGITALER FLACHBILDFERNSEHER TELEVIZOR DIGITAL CU ECRAN PLAT LCD / LED ТЕЛЕВИЗОР FLAT DIGITALNI TV PRIJAMNIK FLAT DIGITALNI TV ZARAVAN DIGITALNI TELEVISOR
Quick Start Guide 1 Insert the batteries into the Remote Control Insert two AAA/R3 or equivalent type batteries inside. Observe the correct polarity (+/-) when inserting batteries and replace the battery cover.
5 HDMI input PLEASE ENSURE BOTH UNITS ARE SWITCHED OFF BEFORE CONNECTING. Use a HDMI to HDMI cable to connect the two units together. To select the HDMI input, press the Source button on the remote control. Each time it is pressed the on-screen menu confirms your selection.
7 Connect your TV to the Internet Connectivity feature allows you to connect your TV to the home network wired or wirelessly. You can use this networking system to connect to the Portal or to access photo, video and audio files that are stored on a Media server connected to the network and play/display them on the TV. However, if your TV does not have Wireless USB dongle or doesn’t support internal Wi-Fi feature, you should use wired connection type.
Contents Safety Information................................................... 2 Markings on the Product......................................... 3 Preparation.............................................................. 3 Features.................................................................. 4 Specification............................................................ 5 Remote Control RC 4848 (depending on the model).... 6 TV and Operating Buttons (depending on the model)................................
• Do not expose the TV to direct sunlight, open flames or place it near intense heat sources such as electric heaters. Safety Information CAUTION • Listening in excessive volumes from earphones and headphones may cause hearing loss. RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Markings on the Product Class II Equipment: This appliance is designed in such a way that it does not require a safety connection to electrical earth. Class II Equipment With Functional Earthing: This appliance is designed in such a way that it does not require a safety connection to electrical earth, the earth connection is used for functional purposes. Protective Earth Connection: The marked terminal is intended for connection of the protective earthing conductor associated with the supply wiring.
Notification Features • TV supports Ultra HD (Ultra High Definition - also known as 4K) which provides resolution of 3840 x 2160 (4K:2K). It equals 4 times the resolution of Full HD TV by doubling the pixel count of the Full HD TV both horizontally and vertically. Ultra HD contents are supported from HDMI, USB inputs and over DVB-T2 and DVB-S2 broadcasts.
Waste Disposal: Specification TV Broadcasting Receiving Channels PAL BG/I/DK/LL’ SECAM BG/DK VHF (BAND I/III) - UHF (BAND U) - HYPERBAND Number of Preset Channels 1000 (without satellite) Channel Indicator On Screen Display RF Aerial Input 75 Ohm (unbalanced) Operating Voltage 220-240V AC, 50Hz. 10000 (with satellite) Packaging and packaging aids are recyclable and should principally be recycled. Packaging materials, such as foil bag, must be kept away from children.
Remote Control RC 4848 (depending on the model) 1. Standby: Switches On / Off the TV 2. TV: Displays channel list / Switches among broadcast types / Switches to TV Source 3. Volume +/4. Menu: Displays TV menu 5. OK: Confirms user selections, holds the page (in TXT mode), views channel list (DTV mode) 6. Back/Return: Returns to previous screen, opens index page (in TXT mode) 7. Internet: Opens the portal page, where you can reach many web based applications 8. My button 1 (*) 9.
Connections (depending on the model) Connector Type Mini Scart Connection (bottom) Cables Device Mini Scart adapter cable VGA Connection (bottom) AUDIO IN PC/YPbPr Audio Connection (back) YPbPr/PC Audio Cable HDMI Connection (bottom&side) SPDIF SIDE AV HEADPHONE SPDIF (Optical Out) Connection (back) Side AV (Audio/Video) Connection (side) Side Audio/Video Connection Cable Audio/Video Cable Headphone Connection (side) YPBPR YPbPr Video Connection (back) YPbPr Connection Cable USB Connection
TV and Operating Buttons (depending on the model) Power Connection After unpacking, allow the TV set to reach the ambient room temperature before you connect the set to the mains. Power Cable Connection: IMPORTANT: The TV set is designed to operate on 220-240V AC, 50 Hz socket. Standby/On Source Plug the power cable to the mains socket outlet. Leave at least 10mm space around the TV set. Programme +/Volume +/Note: Press “ ” and “ same time to view main menu.
Environmental Information This television is designed to be environment friendly. To reduce energy consumption, you can follow these steps: If you set the Energy Saving to Minimum, Medium, Maximum or Auto the TV will reduce the energy consumption accordingly. If you like to set the Backlight to a fixed value set as Custom and adjust the Backlight (located under the Energy Saving setting) manually using Left or Right buttons on the remote. Set as Off to turn this setting off.
Analogue: If Analogue broadcast search option is turned on, the TV will search for analogue broadcasts after other initial settings are completed. Additionally you can set a broadcast type as your favourite one. Priority will be given to the selected broadcast type during the search process and the channels of it will be listed on the top of the Channel List. When finished, press OK to continue. You can activate Store Mode option at this point.
Recorded programmes are saved into the connected USB disk. If desired, you can store/copy recordings onto a computer; however, these files will not be available to be played on a computer. You can play the recordings only via your TV. Lip Sync delay may occur during the timeshifting. Radio record is supported. The TV can record programmes up to ten hours. Recorded programmes are split into 4GB partitions.
Start playback with the OK button and activate The same file will be played continuously (repeat) Start playback with the Play button and activate All files in the list will be played once in random order Start playback with the Play button and activate , All files in the list will be continuously played in the same random order. FollowMe TV (depending on the model) With your mobile device you can stream the current broadcast from your smart TV using the FollowMe TV feature.
Maturity Lock: If this option is set, TV gets the maturity information from the broadcast and if this maturity level is disabled, disables access to the broadcast. Note: If the country option in the First Time Installation is set as France, Italy or Austria, Maturity Lock’s value will be set to 18 as default. Child Lock: When Child Lock is set, the TV can only be controlled by the remote control. In this case the control panel buttons will not work.
the option Delete Rec. Timer. The recording will be cancelled. Set Timer on Event / Delete Timer on Event: After you have selected a programme in the EPG menu, press the OK button. Select Set Timer on Event option and press the OK button. You can set a timer for future programmes. To cancel an already set timer, highlight that programme and press the OK button. Then select Delete Timer on Event option. The timer will be cancelled.
About Using Connectivity Feature Broadband ISP connection PC/HDD/Media Player or any other devices that are compatible should be used with wired connection for higher playback quality. Install Nero Media Home software (http://www.nero.com/ mediahome-tv) to your PC to use it as a media server. LAN (ethernet) cable For models without built-in wifi system, connect the wireless adaptor to one of the USB inputs of the TV.
Using Audio Video Sharing Network Service Audio Video Sharing feature uses a standard that eases the viewing process of digital electronics and makes them more convenient to use on a home network. This standard allows you to view and play photos, music and videos stored in the media server connected to your home network. 1. Nero Media Home Installation The Audio Video Sharing feature cannot be used if the server programme is not installed onto your PC.
list and press the OK button to connect. If “Device connected” message is displayed, the connection is successfully established. If the connection fails try it again. Note: Wireless devices may operate within the same radio frequency range and may interfere with one another. To improve the performance of your wireless device place it at least 1 meter away from any other wireless devices.
AV and HDMI Signal Compatibility Source EXT (SCART) Side AV YPbPr PC Input Typical Display Modes Supported Signals Available PAL O SECAM O NTSC4.43 O The following table is an illustration of some of the typical video display modes. Your TV may not support all resolutions. NTSC3.58 RGB 50/60 O PAL O SECAM O NTSC4.43 O NTSC3.
Supported Video File Formats for USB Mode Video Codec Resolution Bit Rate MPEG program stream (.DAT, .VOB, .MPG, .MPEG), MPEG transport stream (.ts, .trp, .tp), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf) MPEG1/2 MPEG4 Container 1080Px2@30fps, 1080P@60fps 40Mbps XviD Sorenson H.263 H.263 MPEG program stream (.MPG, .MPEG), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf) MP4 (.mp4, .mov), AVI (.avi), MKV (.mkv), ASF (.asf) FLV (.flv), AVI (.
Supported Audio File Formats for USB Mode Audio Codec Sample rate Bit Rate Container MPEG1/2 Layer1 16KHz ~ 48KHz 32Kbps ~ 448Kbps MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), MPEG transport stream (.ts, .trp, .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG), WAV (.wav) MPEG1/2 Layer2 16KHz ~ 48KHz 8Kbps ~ 384Kbps MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), MPEG transport stream (.ts, .trp, .tp), MPEG program stream (.DAT, .VOB, .MPG, .MPEG), WAV (.
Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information.
Internet Portal functionality information The content and services available through the SmarTVue portal are provided by third-party providers and may be altered, suspended or discontinued at any time without notice. Hitachi is not responsible for any of the content or services and does not warrant the availability of or access to such content or services. For information on a particular service or on any content, please visit the service/content provider’s website.
