EN Super Cub S NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-todate product literature, visit www.horizonhobby.com and click on the support tab for this product.
EN Super Cub S Included in the Box Bags A Includes Transmitter B C For more information and to register your product online, visit www.hobbyzonerc.com Flying Tips 600 feet (183 m) • Sensor Assisted Flight Envelope (SAFE®) technology is designed as flight assistance, not an autopilot. The pilot is always in control and required to fly the aircraft at all times. • Start in Beginner mode (SAFE switch position 0). As you learn and become more confident, change modes to advance your flying skills.
EN Super Cub S Charging the Flight Battery Flashing (Charging) CAUTION: When connecting the battery to the battery charger, make sure the connectors are aligned as shown. Failure to connect the battery properly could cause the terminals to short and result in fire, personal injury and/or property damage. Solid (Charged) 1 hour Charger Specifications • Input power: 10–14V • Max output voltage: 11.1V • Fixed charge current: 1.
EN Super Cub S Transmitter Binding The included RTF transmitter should be bound to the aircraft at the factory, but if you need to re-bind, follow the binding procedure as shown. You need to ‘bind’ your chosen Spektrum™ DSM2®/DSMX® technology equipped aircraft transmitter to the receiver for proper operation. Please refer to the optional parts list in this manual or visit www.bindnfly.com for a list of compatible transmitters. Binding Procedure Reference Table 1.
EN Super Cub S Assembly continued Gently flex Tail Installation x2 Bag C Clevis adjustment Elevator Control Linkage Install Rudder Control Linkage Install Control Horn Clevis Clevis Control Horn Wing Installation x2 Bag B x4 Bag B IMPORTANT: The rubber bands prevent wing damage from impact. Always replace worn or broken rubber bands.
EN Super Cub S Installing the Flight Battery Lower the throttle and throttle trim, then power on the transmitter for at least 5 seconds. Mode 2 CAUTION: Always disconnect the Li-Po flight battery from the aircraft receiver when not flying to avoid over-discharging the battery. Batteries discharged to a voltage lower than the lowest approved voltage may become damaged, resulting in loss of performance and potential fire when batteries are charged.
EN Super Cub S Control Direction Test Perform the Control Direction Test with the transmitter SAFE flight mode switch set to Experienced mode (position 2). Back 0 Up Elevator (climb) Front 1 2 Down Elevator (descend) Experienced SAFE Flight Mode Restrain the aircraft so it does not escape your control while you are testing your transmitter controls. Move the sticks on the transmitter* to ensure the aircraft responds as shown.
EN Super Cub S Range Check Before each flying session, and especially with a new model, you should perform a range check. The DXe incorporates a range testing system. Placing the transmitter in RANGE CHECK mode reduces the output power, allowing a range check. Mode 2 Keep immobile and out of the wind for 5 seconds Mode 1 1 3 2 1. Power on the transmitter for 5 seconds or more with the throttle stick and trim low. Power on the ESC Switch and keep the aircraft immobile for at least 5 seconds. 2.
EN Super Cub S Takeoff Hand Launch Hand launch in Beginner mode for first flights. Get help to hand launch your aircraft so you can concentrate on flying. If you must hand launch the aircraft alone, hold the model in your dominant hand and the transmitter in your other hand. An optional neck strap (SPMP610, sold separately) can help you hold the transmitter. Easy Launching Climbs at 100% throttle Wind 0–7 mph (0–11km/h) Launching is easier in Beginner mode if you hold the Panic Recovery button.
EN Super Cub S Flying In Beginner mode, when properly trimmed, your aircraft will climb at full throttle without use of the elevator stick. • The aircraft flies 7 minutes or more on a battery charge, using proper throttle management. • If the motor pulses, land the aircraft immediately and recharge the flight battery. • Make small and steady control stick movements for smooth control of your aircraft.
EN Super Cub S Optional Transmitter Setup If using any DSMX transmitter other than the included DXe (3 pos gear switch) the radio will have to be configured correctly for the SAFE system to work properly. Refer to your transmitter’s manual for more information about transmitter setup. If you are using a 2 position switch for SAFE flight modes, only Beginner and Experienced modes will be active.
EN Super Cub S Low Voltage Cutoff (LVC) NOTICE: Repeated flying to when the motor pulses will damage the battery. For your first flights, set a timer for 7 minutes to avoid flying until the motor pulses. Adjust your timer for longer or shorter flights once you have flown the aircraft. • The aircraft protects the flight battery from accidental over-discharge by applying LVC, removing power supplied to the motor. • LVC causes the motor to pulse, but power remains to steer the aircraft.
EN Super Cub S Troubleshooting Guide Problem Possible Cause Damaged propeller or spinner Loose or damaged spinner, propeller, motor or gear box parts Loose receiver Aircraft oscillates Loose aircraft controls Worn parts Trim is at extreme and aircraft does not fly Trim is not at neutral straight or level Throttle not at lowest position or throttle Aircraft will not retrim too high spond to throttle but responds to other Throttle channel is reversed controls Motor disconnected from Receiver/ESC Damaged
EN Super Cub S Service and Repair NOTICE: If you replace the receiver, install the new receiver in the same orientation and manner as the original receiver or damage may result. H I Thanks to the Z-Foam™ material in the wing and fuselage of this aircraft, repairs to the foam can be made using virtually any adhesive (hot glue, regular CA (cyanoacrylate adhesive), epoxy, etc). However, use only foam-compatible CA, foam-compatible accelerant or epoxy on the vertical and horizontal tail material.
EN Super Cub S Limited Warranty What this Warranty Covers Horizon Hobby, LLC, (Horizon) warrants to the original purchaser that the product purchased (the “Product”) will be free from defects in materials and workmanship at the date of purchase. you in the event that you may need any assistance. For questions or assistance, please visit our website at www.horizonhobby.
EN Super Cub S Warranty and Service Contact Information Country of Purchase United States of America Horizon Hobby Horizon Service Center (Repairs and Repair Requests) Horizon Product Support (Product Technical Assistance) Sales United Kingdom Germany France Service/Parts/Sales: Horizon Hobby Limited Horizon Technischer Service Sales: Horizon Hobby GmbH Service/Parts/Sales: Horizon Hobby SAS Contact Information servicecenter.horizonhobby.com/ RequestForm/ productsupport@horizonhobby.
Super Cub S Replacement Parts • Ersatzteile • Pièces de rechange • Pezzi di ricambio Part # | Nummer Description Numéro | Codice Beschreibung Description 9 x 6 Propeller DC LiPo Balancing Charger 1.5A AC Power Supply DSMX SAFE Receiver/ ESC unit: Super Cub 1300mAh 11.1V Li-Po Battery with EC3 Connector 9 x 6 Propeller Hobbyzone 3S Lipo Balance Lader Hobbyzone 1.5A Netzteil DSMX SAFE Empfänger / Regler Einheit Hélice 9x6 Parkzone 11.1V 1300mAh LiPo Bat m/EC3 Stecker Batterie Li-Po 3S 11.
Super Cub S Optional Parts • Optionale Bauteile • Pièces optionnelles • Pezzi opzionali Part # | Nummer Description Numéro | Codice HBZ7390 PKZ1005 EFLAEC312 HBZ6513 Super Cub LP Floats Beschreibung Hobbyzone Schwimmersatz für Super Cub LP High Power Luftschraube 10 x8 (bei Verwendung mit Schwimmern) 10 x 8 High Power Propeller (for use with optional floats) EC3 Charge Lead w/12” EC3 Ladekabel mit Stecker Wire & Jacks,16AWG Alligator Clip: 12V Lighter Adapter 1.
