Installation Guide

32 33
Parts indented are included in the assembly under which they are indented.
ITEM PART NO. QTY. DESCRIPTION
23100/23150 HomePlow Manual Lift
1 14001 1 • LiftFrameAssembly  
 2 13998 1 • A-Frame
 3 13988 1 • PivotBar
 4 09456 1 • MoldboardAssemblyRight
 5 13951 1 • MoldboardAssemblyLeft  
 6 09449YEL 1 • CuttingEdgeMiddle
 7 09450YEL 2 • CuttingEdgeOuter
  08388 1 • ManualLiftCarton  
 8 13286 4 ••TripSpring
 9 14016 1 ••ManualHandleAssembly  
 10 14009 1 ••ManualLatchHandle
 11 14011 1 ••ManualleafSpring
 12 14003 1 ••ManualLatchWeldment
 13 14007 1 ••ManualLatchRungLock
 14 14008 2 ••SpacerTube
 15 13984 2 ••CompressionSpring
 16 13986 2 ••SpringArm
 17 13987 2 ••SpringArmCover
 18 13985 2 ••PivotArm
 19 09917 1 ••PlowMarkerKit
 20 13969 1 ••SpacerPlate
  08956 1 ••HardwareBag
 21 22851 4 •••Eyebolt3/8-16x4”
 22 20526 4 •••FinishNut3/8-16
 23 20305 6 •••Locknut3/8-16
 24 20094 5 •••BoltH1/2-13x1-1/4”Gr.5
 25 20307 14 •••Locknut1/2-13
 26 21943 8 •••BoltC1/2-13x1-3/4”Gr.5
 27 22850 2 •••ClevisPin1/2x1-1/4”
 28 22845 3 •••HairPinCotter1/8”
 29 20147 1 •••BoltH5/8-11x3-1/2”Gr.5
 30 20309 1 •••Locknut5/8-11
 31 11101 2 •••HingePin
 32 22436 2 •••Pin1x3”
 33 20420 2 •••CotterPin1/4x2”
 34 22083 1 •••LynchPin   
 35 20102 1 •••BoltH1/2-13x3-1/4”Gr.5
 36 22942 1 •••ClevisPin3/8x3”
 37 20003 6 •••BoltH1/4-20x3/4”Gr.2
 38 20351 6 •••Flatwasher1/4”
 39 20303 7 •••Locknut1/4-20
 40 20049 2 •••BoltH3/8-16x1”Gr.2
 41 20019 1 •••BoltH1/4-20x2-1/2”Gr.2
PARTS LIST
HOMEPLOW
Manual Lift
32
