OPERATOR’S MANUAL 7.2 VOLT Grass shear/shrubber UT44170 Your grass shear/shrubber has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance. WARNING: To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. Thank you for your purchase.
TABLE OF CONTENTS Introduction....................................................................................................................................................................... 2 Important Safety Instructions.........................................................................................................................................3-4 Specific Safety Rules...................................................................................................................
important safety instructions hands of untrained users. Use only original manufacturer’s replacement parts. Failure to do so may cause poor performance, possible injury, Read and understand all instructions. When using and will void your warranty. electric gardening appliances, basic safety precautions Do not, under any circumstance, use any attachment or should always be followed to reduce the risk of fire, accessory on this product which was not provided with electric shock and personal injury.
important safety instructions Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. Under abusive conditions, liquid may leak from the battery, avoid contact. If contact accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help. Liquid leaking from the battery may cause irritation or burns.
SAFETY RULES FOR CHARGER WARNING! Read and understand all instructions. Failure to follow all instructions listed below, may result in electric shock, fire and/or serious personal injury. Before using battery charger, read all instructions and cautionary markings in this manual, on battery charger, battery, and product using battery to prevent misuse of the products and possible injury or damage.
SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME EXPLANATION V Volts Voltage A Amperes Current Hz Hertz Frequency (cycles per second) W Watt Power hrs Hours Time Class II Construction Double-insulated construction Wet Conditions Alert Do not expose to rain or use in damp locations.
SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNING: Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury.
FEATURES FEATURES PRODUCT SPECIFICATIONS Cutting Capacity........................................................ 3/8 in. Motor . ....................................................................7.2 V DC Total Blade Length......................................... 4 in. and 6 in. Charger Input.....................................120 V, AC only, 60 Hz Weight (shear mode)................................................. 2.1 lbs.
ASSEMBLY UNPACKING connecting the poles This product requires assembly. See Figure 2. n Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included. n Inspect the product carefully to make sure no breakage or damage occurred during shipping. n Do not discard the packing material until you have carefully inspected and satisfactorily operated the product. n If any parts are damaged or missing, please call 1-800-242-4672 for assistance.
OPERATION WARNING: Do not allow familiarity with this product to make you careless. Remember that a careless fraction of a second is sufficient to inflict serious injury. WARNING: Always wear safety goggles or safety glasses with side shields when operating power tools. Failure to do so could result in objects being thrown into your eyes, resulting in possible serious injury. Fig. 3 OR WARNING: Do not use any attachments or accessories not recommended by the manufacturer of this product.
OPERATION Install padlock (not included) or lockout pin into switch trigger slot. Keep both hands away from switch. switch trigger NOTE: The lockout pin does not protect against unauthorized usage. Unlatch and remove the bottom cover. Remove the attached blade, if necessary. Install the desired blades into the slot on the bottom of the grass shear/shrubber. Reattach the bottom cover by sliding it into the slots on the bottom of the grass shear/shrubber until it clicks into place.
OPERATION CUTTING TIPS See Figures 7 - 8. WARNING: Clear the area to be cut before each use. Remove all objects such as cords, lights, wire, or loose string which can become entangled in the cutting blade and create a risk of serious personal injury. Do not force the shrubber through heavy shrubbery. This can cause the blades to bind and slow down. If the blades slow down, reduce the pace. Do not attempt to cut stems or twigs that are larger than 3/8 in.
MAINTENANCE LUBRICATING THE BLADE WARNING: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. See Figure 9. For easier operation and longer blade life, lubricate grass shear/shrubber blades before and after each use. If you will be using the grass shear/shrubber for an extended period, it is advisable to oil the blade during use. Stop the motor.
MAINTENANCE BATTERY PACK REMOVAL AND PREPARATION FOR RECYCLING Stop the motor. Install padlock (not included) into switch trigger slot. Keep both hands away from switch. Hold one wheel while turning other wheel counterclockwise to remove wheel. Remove wheel and remaining attached wheel and axle. Remove the screws securing motor housing cover, then remove cover. Lift batteries from motor housing enough to expose leads and battery terminals.
EXPLODED VIEW AND PARTS LIST 8 9 4 5 1 10 3 7 6 2 Key No. 1 2 3 4 5 6 7 8 9 10 Part Number 31101251G 31102251G 34106251G 33201251G 34108251G 34109251G 34105251G 36901251G 31103251G 34112251G 987000219 Description Qty. Grass Shear Blade...................................................................................................... 1 Shrubber Blade...........................................................................................................
WARRANTY LIMITED WARRANTY STATEMENT Homelite Consumer Products, Inc., (“Homelite”) warrants to the original retail purchaser that this HOMELITE brand outdoor product is free from defect in material and workmanship and agrees to repair or replace, at Homelite’s, discretion, any defective product free of charge within these time periods from the date of purchase.
NOTES Page 17
OPERATOR’S MANUAL 7.2 VOLT Grass shear/shrubber UT44170 SERVICE For parts or service, contact your nearest Homelite authorized service dealer. Be sure to provide all relevant information when you call or visit. For the location of the authorized service dealer nearest you, please call 1-800-242-4672 or visit us online at www.homelite.com. REPAIR PARTS The model number of this tool is found on a plate or label attached to the housing. Please record the serial number in the space provided below.
