Tuxedo Touch Series Home Automation System User Guide 800-08091V3 4/13 Rev.
Table of Contents ABOUT THE SYSTEM ............................................................................................................................................................................... 5 Introduction .......................................................................................................................................................................................... 5 System Interface ................................................................................
Table of Contents How to Clear/Hide a Control Panel Message ............................................................................................................................. 16 Advanced System Features ....................................................................................................................................................... 16 Console Emulation Mode ........................................................................................................................
Table of Contents Setting Daylight Savings Time.................................................................................................................................................... 29 Setting Current Time and Date ................................................................................................................................................... 29 USER SYSTEM SETUP ..................................................................................................................
About the System Introduction Congratulations on your ownership of a Honeywell Tuxedo Touch™ Home Automation System which combines home automation and home security. With clear, simple controls on a touch-screen interface, Tuxedo Touch™ is both easy to learn and easy to use. A Product/Training Video is provided containing easy step by step tutorials to assist with the setup and customization of the system.
About the System (cont'd) About Your Home Screen Your "Home" screen is the gateway to your System. From this screen you can: • control your security system • control your multi-media applications such as video, pictures and cameras • control home automation such as lighting, thermostat, and door locks. Your "Home" screen is displayed most of the time and can be customized via the Multi-Media Application.
About the System (cont'd) Navigation Icon Descriptions To aid in the navigation of the Tuxedo Touch, a set of user-friendly icons has been provided. The appearance and function of these icons are described below. ICON ICON TITLE FUNCTION ICON ICON TITLE “Product / Training Videos” Accesses Product Introduction and Training Videos. “Setup” "Automation” Accesses the Z-Wave setup, Scene setup, and Room setup screens.
About the System (cont'd) System Troubles The “Security” screen also displays an Icon(s) if a system trouble(s) occurs. If a Trouble Icon is shown, contact your alarm company. The following Icons may be shown as applicable to your system: ICON FUNCTION AC Loss – The system is not receiving AC power. Bell Failure – The system bell or siren has a problem. Note: This Icon displays when interfacing with residential panels only. Expander Failure – The system has a failure in an expansion module.
About the System (cont'd) User Codes Each user must be assigned a name with a corresponding 4-digit user code in order to gain access to authorized features and functions. Users for the system are programmed in a central user setup location that provides the specific questions for authorization level, partition assignment, and RF zone assignment.
Security Introduction to Security System Operation You can arm the system in one of three arming modes: Away, Stay, and Night. The following table lists the three different arming modes and the results of each. FEATURES FOR EACH ARMING MODE Arming Mode FUNCTION Exit Delay Entry Delay Perimeter Armed Interior Armed AWAY Press to arm when no one is staying on the premises.
Security (cont'd) How to Arm the System Arming the system in any mode is performed in the same way, as described below. Note: Close all perimeter windows and doors before arming. Arm the system as follows: ICON ACTION 1. From the “Home” screen, press the SECURITY icon. 2. Press the selected arming icon.
Security (cont'd) How to Display Faults The Display Faults function is used when you see a “Not Ready Fault” message and want to determine where the fault is and what type of fault it is. To display faults do the following: ICON ACTION NOTES 1. From the "Security" screen, press the A listing of faulted and/or bypassed zones is displayed. 2. If the fault cannot be corrected, you may As applicable, take corrective action such as closing a window or door to correct the fault. DISPLAY FAULTS icon.
Security (cont'd) ICON ACTION 6. Press the BACK icon to return to the “Arming” screen. NOTES The "More Choices" screen is displayed showing the system status as ReadyBypass. How to Clear Bypassed Zones A bypassed zone is automatically unbypassed when you disarm the system. If a zone is bypassed, you can remove the bypass as follows: ICON ACTION 1. Press the SHOW ZONES icon. 2. Press the CLEAR BYPASSES icon. 3. Enter your 4-digit user code.
Security (cont'd) To disarm Multi-Partitions do the following: ICON ACTION 1. From the “Home” screen, press the Security icon. 2. Press the Arm Multi-Partition icon. 3. Press the Disarm icon. 4. Enter your 4-digit user code. 5. Highlight the partition(s) to disarm and press OK, or press ALL to disarm all partitions. NOTES The keypad displays “Multi-Partition Arming”. How to Check the Status of Other Partitions This system supports between one and eight Partitions (depending on the system.
Security (cont'd) UL CO annunciation has not been investigated by UL and may not be used for UL installations. In Case of Fire Alarm 1. 2. 3. 4. A FIRE message appears at your keypad and remains on until you silence the alarm. Should you become aware of a fire emergency before your detectors sense the problem, go to your nearest keypad and manually initiate an alarm by pressing the panic key assigned as FIRE emergency (if programmed by the installer) and hold down for at least 2 seconds.
Security (cont'd) More Choices How to Clear/Hide a Control Panel Message The Control Panel Message icon alerts the user to a control panel message. When a Control Panel Message is displayed, the user has two options. User can clear the Control Panel Message immediately, or minimize the window and clear it at a later time. To Clear/Hide the Control Panel Message, do the following: ICON ACTION 1. To clear; press CLEAR. 2. Enter your Authorized Code or, 3.
Security (cont'd) How to View the Event Log Your system has the ability to record various events in a history log wherein each event is recorded with the time and date of its occurrence. The control panel must be programmed to record various system events in the installer programming mode. To view the Event Log, perform the following: ICON ACTION 1. From the “Home” screen, press Security and then the MORE CHOICES icon. 2. Press the EVENT LOGS icon; the first ten events are displayed. 3.
Setup Setup allows you to make changes to the way your keypad is operating. You may access the Brightness and Volume, Display & Audio Setup, IP Setup and System Setup from the "Setup" screen. Brightness and Volume Control From the "Home" screen, access the "Setup" screen as follows: ICON ACTION NOTES If changes are made, when you exit a Settings Changed! pop-up window is 1. Press the Setup icon. displayed asking “Remember New Settings?“ 2. Move the Brightness/Volume slide bar up or Yes saves the change.
Setup (cont'd) Note: If using a Z-Wave thermostat with Celsius as your degree preference, the temperature can be adjusted by 0.5 degree increments. Adjust the Screen Timeouts When the keypad is left idle, it automatically: • turns the “Backlight Off After” the selected backlight off time has expired (unless “Never” option is selected).
Setup (cont’d) Web Server/Hosting The Tuxedo Touch keypad offers web-hosting capability allowing you to access your Security and Home Automation System via any web enabled device. The Tuxedo Touch Keypad’s ‘IP Address’ is used on a standard web browser to control user functions such as, Security, Z-Wave operation, and camera viewing. UL Web Server/Hosting is not Listed for use in UL installations. Remote arming/disarming/programming is not to be used in UL Listed Installations.
Setup (cont'd) Fixed IP Addresses If the IP Address is not displayed in the lower left-hand corner on the Tuxedo Touch Keypad “Home” screen, you may require a “Static” (Fixed) IP Address that can be found by accessing your router. Refer to your router instructions for further information. To access “IP Setup”, do the following: ICON ACTION NOTES 1. At the Tuxedo Touch Keypad: a) Press the Setup icon and then press the Use the Data Entry Keyboard to enter the required information.
Multi-Media The Multi-Media feature allows you access voice messages, play video files, display a slide show of personal photos, and view up to four cameras at once from your keypad. UL Multi-Media functionality is supplementary only and has not been evaluated by UL. Voice Messages The Tuxedo Touch Keypad can record voice messages for others on the premises. The number of messages is not limited; however, the total time of all messages added together cannot exceed 120 seconds.
Multi-Media (cont'd) Video (Audio) Setup To access the Video and Audio feature, do the following: ICON ACTION 1. Insert your personal media (SD/SDHC) card (with stored video files). 2. Press the Multi-Media and Video icons. NOTES A Video Converter is required to convert videos for proper playback on the Tuxedo Touch Keypad. Use an Internet search engine to locate and download a Video Converter, then follow the steps in the Video Converter Instructions (provided in the carton). NOTES: 3.
Multi-Media (cont’d) ICON ACTION 6. To remove an image from the slide show, select the image, and press the Deselect Image icon. To set a picture as wallpaper: 1. Use the slide bar to scroll through the list of pictures and highlight the file you want to be displayed on the keypad screen. 2. Press the Set Wallpaper icon; view your selection from the “Home” screen. NOTES Press the TOP button to move up one level in the directory.
Multi-Media (cont'd) ICON ACTION NOTES Use the Data Entry Keyboard to enter the required information. 5. Press the Add icon (if the camera information is • Use the Shift key for capital letters not automatically obtained), to manually enter • Use the BS (Backspace) key to make corrections. information. Press the Clear icon to clear the camera list. 6. To edit camera information, highlight the On the ‘Add Camera’ screen enter (Name, User, RTSP Path, camera name and press the Edit icon.
User Setup User Setup allows you to Add a User, Delete a User, and Edit a User. You may access User Setup from the System Setup screen. Each user must be assigned a name with a corresponding 4-digit user code in order to gain access to various features and functions. The keypad can hold the identity for 10 Users in its memory. If additional Users are needed, define the additional Users using the Console Emulation Mode.
User Setup (cont'd) ICON ACTION 7. Press the box next to User Number and enter an “available” (3-digit) user number; press the OK icon. 8. Press the box next to Enter User Code, enter the 4-digit User Code for this user and press the OK icon. 9. Press the box next to RF Button Zone (if used); enter the 3-digit RF Button Zone for this user. 10. Press the Save icon. NOTES The authorized code for adding users is dependent upon the alarm panel you are interfacing with.
User Setup (cont'd) Safe Mode The Safe Mode may be automatically entered by the program on a communication failure or may be entered manually on command. To Exit the Safe Mode: 1. Press the ! SAFE MODE ! bar. 2. Select “Yes” to return to the Normal Mode of operation. The keypad resets and normal operation returns as long as the original conditions that caused the entry into Safe Mode do not still exist. ICON ! SAFE MODE ! ACTION 1. Select Safe Mode and then press Apply.
User Setup (cont'd) Time/Date Setup You can set the time and date from the Set Time & Date screen. • When the time is set it is stored in the keypad and sent to the control panel when you press the Apply icon and answer Yes to the following prompt. Additionally, when using the keypad, the panel may download its time into the keypad periodically after the clock is set (for Vista residential and newer commercial panels such as Vista 128BPT).
User System Setup Advanced Setup Advanced Setup allows access to the System Information, Keypad Reset, Keypad Test, Night Setup and Output Setup menus. System Information To view the latest software version installed on your system, do the following: ICON ACTION NOTES The Software Version is displayed on the lower right of screen. 1. From the “Setup” screen, press the System If necessary visit the Tuxedo Toolkit at: Setup and then the Advanced Setup icons. http://www.tuxedotouchtoolkit.com/index.
User System Setup (cont'd) LED Test ICON ACTION 1. Press the LED Test icon; "Testing.." is displayed while the 3 LEDs light sequentially, top to bottom (red, green, yellow), 5 times. NOTES At the conclusion of the test, a pop-up "Confirmation Window" displays: "Did you see chasing LED pattern?" If you press Yes, "Passed" is displayed in the test status column. If you press No, "Failed" is displayed in the test status column. Calibration Test ICON ACTION NOTES A pop-up message displays: 1.
User System Setup (cont'd) ICON ACTION 7. Select the Z-Wave Basic Command Set On icon to turn On all lamp modules, dimmer On/Off switches and receptacles. NOTES Note: This command does not control door locks or any other security enabled devices. 8. Select the Z-Wave Basic Command Set Off icon to turn Off all lamp modules, dimmer On/Off switches and receptacles.
Automation The Tuxedo Touch Home Automation System with web hosting capability is equipped with Z-Wave technology and is designed to automate devices in a home control network. The keypad allows you to easily add and control multiple devices with the press of a button. View the Training Videos and follow the instructions below to Enroll (add) devices into your home control network. NOTE: Z-Wave applications have not been evaluated by UL.
Automation (cont'd) Enroll a Door Lock Assemble the Z-Wave door lock. NOTE: Be sure the door lock orientation/handedness is correct. Refer to the Door Lock’s Instruction Guide and connect necessary cables, then install batteries. Enroll the door lock within 5 ft of the keypad; refer to the Door Lock’s Instruction Guide for enrollment procedure. NOTE: Program the user code in the control panel prior to programming that user code into the door lock. User Codes must be 4digits.
Automation (cont'd) Editing Z-Wave Device Names Edit a Device Module Name To edit a device name, do the following: ICON ACTION NOTES 1. At the Tuxedo Touch Keypad: a) Press the Automation icon from the “Home” screen and press the Z-Wave Setup icon to display the “ZWave Device Management” screen. b) Highlight the device name and press the Z-Wave Edit icon. c) On the “Data Entry” keyboard, press Clear and enter a new name. d) Press OK. Enter the new device name on the data entry keyboard.
Automation (cont'd) Remove/Delete a Honeywell Thermostat To remove a Honeywell Thermostat from the Z-Wave network, do the following: ICON ACTION NOTES 1. At the Tuxedo Touch Keypad: IMPORTANT: Honeywell is not responsible for property damages a) Press the Automation icon from the “Home” screen, due to improper setting of the thermostat modes. and then press the Z-Wave Setup icon to display the “Z-Wave Device Management” screen. b) Highlight the thermostat and press the Z-Wave Remove/Delete icon.
Automation (cont'd) Scene Setup The “Scene” feature is used to control the function of a single device, or multiple devices based on pre-set Conditions, Triggers, and Actions. When the trigger/condition occurs, the action is executed. Define a Scene as follows: ICON ACTION NOTES Enter the new device name by entering it on the data entry keyboard. 1. At the Tuxedo Touch Keypad: • Use the Shift icon for capital letters.
Automation (cont'd) Scene Setup Options Options for adding a Condition (if needed) – After each selection press SAVE!!! In the “Condition” box, press the Add icon. To set the time, press the TIME button: “Set the occurrence” to Repeated, or Once. If “Repeated” was selected, choose the desired days of the week; if ONCE was selected Enter Date. The Time can be set to execute automatically at Sunrise or Sunset by pressing the Sunrise/Sunset option.
Automation (cont'd) Notes: 1. Motorized door lock bolts physically lock and unlock the door when activated, but if the door lock installed is a non-motorized type, activation allows the door to be manually unlocked without a key. See “Compatible Devices” section for further information. 2. Some thermostats do not update temperature status automatically (i.e., Wayne Dalton). 3.
Automation (cont'd) Updating Controllers (Keypads) with New or Removed devices When devices are added or removed from the Z-Wave network, the device information needs to be updated in the Controllers. To update this information you do not have to remove the device first. From the Primary controller, do the following: ICON ACTION 1. Press Add on Primary controller. 2. Press Add on Secondary controller. NOTES The controller scans for device changes.
Automation (cont'd) Remote Services The Tuxedo Touch™ supports Remote Services for controlling Z-Wave devices and scenes remotely from an associated Total Connect account.
Automation (cont'd) Controlling Automation (Z-Wave) Devices Remotely Use Total Connect to control Z-Wave devices: lamp modules (binary switch), dimmer modules (multilevel switch), thermostats, etc., from a smart phone, i-PadTM, AndroidTM Tablet, Blackberry® or PC. 1. Access the Total Connect account and navigate to the Automation section of the dashboard. 2. Select a displayed device and click the desired action. Refer to the Total Connect online help guide for further details on controlling Z-Wave devices.
Automation (cont'd) 2. The “Total Connect Server Setup” screen is displayed with the current Server information and Z-Wave Status (enabled/disabled). NOTE: These fields are for reference only and cannot be edited. 3. Press the Connect icon to test the connection to the AlarmNet servers. Compatible Devices Z-Wave devices may vary; follow the instructions in the Users Guide for your specific device when adding and deleting devices into the Z-Wave network.
Important Notes Wireless Range This device complies with the Z-Wave® standard of open-air, line of sight transmission distances of 100 feet. Actual performance in a home depends on the number of walls between the controller and the destination device, the type of construction and the number of ZWave enabled devices installed in the control network. Please Note: Z-Wave home control networks are designed to work properly alongside wireless security sensors, Wi-Fi, Bluetooth and other wireless devices.
Glossary The following terms are used throughout the guide. Arm/Disarm: “Armed” simply means that the burglary portion of your system is turned ON and is in a state of readiness. “Disarmed” means that the burglary system is turned OFF, and must be rearmed to become operational. However, even in a “disarmed” state, “emergency”, "carbon monoxide" and “fire” portions of your system are still operational. Bypass: To intentionally leave a specific zone unprotected while the rest of the system is armed.
FEDERAL COMMUNICATIONS COMMISSION STATEMENTS The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's Manual. Unauthorized changes or modifications could void the user's authority to operate the equipment. FCC CLASS B STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use.
TWO YEAR LIMITED WARRANTY Honeywell International Inc.
