L-Series LCD Monitor User Manual Controls and Functions The HMLCD17L and HMLCD19L monitors include the following features: • • • • OSD menu MPR II certified DDC1 and DDC2 plug and play functionality Full range power supply that auto adjusts to accept AC 100V to 240V and 50Hz to 60Hz Front Panel Controls Figure 1 Front panel controls HMLCD17L 1 2 3 1 2 4 5 6 HMLCD19L Document 800-00945 Rev A 09/07 1. AUTO button 2. OSD t button 3. OSD s button 4. OSD MENU button 5. Power switch 6.
Controls and Functions Back Panel Controls Figure 2 Back panel connectors 1. Audio-in 2. DC power-in 3. VGA-in (D-Sub connector) 4. Video-in (RCA) 5. Video2-in (BNC) 6. Video3-in (BNC) 7. Video3-loop-out (BNC) 8. Audio-in-Right (Video mode) 9. Audio-in-left (Video mode) How to Install the Power Cable: 12 1. Plug the AC/DC adapter into the DC power-in. 2. Connect the AC power cable to the adapter. 3. Connect the VGA cable to the D-Sub connector. 4.
L-Series LCD Monitor User Manual OSD Menu Using the menu: There are two options for configuring the Monitor display: AUTO and MENU. Press AUTO to configure the monitor automatically without user input. Press MENU to enable the monitor to be configured using the OSD menus described below. To scroll through the main menu and select sub menu options use the s and t buttons on the front panel of the monitor. To change a menu setting use the and options.
OSD Menu Picture: Figure 4 Picture settings H Position Move the picture horizontally on the screen right and left. V Position Move the picture vertically on screen up and down. Phase Adjust the number of horizontal picture elements. Clock Adjust the vertical noise of the screen image. Sharpness Adjust background black level of the screen image. Function: Figure 5 Function settings Auto Adjust Select whether to enable the auto adjust feature of the monitor.
L-Series LCD Monitor User Manual OSD Menu: Figure 6 OSD Menu settings Language Select the required supported language from the list. OSD H. Position OSD window horizontal position adjustment. OSD V. Position OSD window vertical position adjustment. OSD Timer Set the OSD screen standby time. Translucent Set the translucency of the OSD. Misc: Figure 7 Misc settings Signal Source Select the signal source for the monitor. Mode Select Select the screen resolution.
OSD Menu Volume Adjust the monitor audio volume.
L-Series LCD Monitor User Manual Power Management The power management function for this monitor is controlled by the computer to which it is connected. This monitor enters an appropriate mode as designated by the computer.The stage that the power management system is in is indicated by the LED on the monitor.
Specifications and Parts Specifications and Parts Figure 8 Monitor dimensions HMLCD17L 388mm 388mm 98.56" 15.28" 390mm 390mm 15.35" 99.06" 42.67" 6.61" 168mm HMLCD19L 16.61" 422mm 16.69" 424mm 6.
L-Series LCD Monitor User Manual Table 3 Parameter Description LCD Type Pixel pitch(mm): 0.264(H) 0.264(W) Maximum Pixel Rate: 100MHz Display Color: 16.7 M Viewing Angle: 85/85(H) 70/70(V) Resolution (H x V) 1280 x 1024 @ 60Hz Frequency Horizontal: 31-81KHz Vertical: 56-75Hz Input Signal Analog RGB(0.7Vp-p, 75Ù ohms) D-Sub / BNC / RCA Active Display Area (W x H) 17": 337.9mm(13.3") x 270.3mm(10.6") 19": 376.3mm(14.8") x 301mm(11.9") Dimensions (W x H x L) 17": 400mm(15.7") x 385mm(15.
Specifications and Parts Table 4 Pre-Set Display Mode Mode Resolution Horizontal Frequency 17" 19" 12 1024 x 768 56.5 KHz / 70.1 KHz v v 13 1024 x 768 60.0 KHz / 75.01 KHz v v 14 1280 x 1024 64.6 KHz / 59.9 KHz v v 15 1280 x 1024 80.05 KHz / 75.0 KHz v v Table 5 Parts list Part Quantity LCD Monitor 1 AC Power Cable 1 Audio Cable 1 VGA Cable 1 DC Power Adapter 1 User Manual 1 Note: technical specifications and parts are subject to change without notice.
L-Series LCD Monitor User Manual Troubleshooting Issue: No image is displayed on screen. Possible • Solution: • • • • Issue: ’Going to Sleep’ message displayed on screen. Possible • Solution: • Issue: Check that the power cord has been connected securely into the wall outlet or grounded extension cable or surge protector. Power switch should be in the ON position and the LED should be lit. Check that the Brightness and the Contrast adjustments have not been turned down to the minimum levels.
Troubleshooting Possible If red, green or blue are not displayed on the screen, check whether the Solution: display cable is properly connected. Issue: Sync problem between the monitor and PC Possible • Solution: • 22 Check if the display input signal is within the specified range (56 - 75 Hz). Ensure the display signal cable is connected properly between the monitor and the PC.
