DIQ722
Information is subject to change without notice. SmartStack is a trademark of Horner APG, LLC.
This datasheet also covers products starting with IC300.
1 SPECIFICATIONS
INPUT DIQ722 DIQ722
Inputs per Module 14 Input Impedance
0.01 µF +10 K
Commons per Module 3
Isolation
(Channel to Ground)
1500 VDC
Input Voltage Range 120–160 VAC Minimum ON Current 1 mA.
Peak Voltage 160 VAC Maximum OFF Current
200 µA.
AC Frequency 50 / 60 Hz OFF to ON Response 50 ms.
ON Voltage Level 70 VAC Min. ON to OFF Response 50 ms.
OFF Voltage level 30 VAC Max.
OUTPUT DIQ722 DIQ722
Outputs per Module 10 relay
Maximum Leakage
Current
5 µA
Commons per
Module
2
Maximum Inrush Current 3 A
Output Type Relay Minimum Load None
Coil Voltage 18–30 VDC OFF to ON Response 6 ms. Typical
Contact Voltage 250 VAC / 30 VDC Max. ON to OFF Response 0.3 ms. Typical
ON Voltage drop 0.2 VDC max.
Maximum Load
current (resistive)
per channel
3 A
See Derating Chart
Isolation
(Channel to Channel and
Channel to Ground)
2500 VDC
General Specifications
Required Power (Steady
State)
0.17 W (7 mA @ 24 VDC) Operating
Temperature
0°–60° Celsius
Required Power (Inrush) Negligible Terminal Type Spring Clamp, Removable
Relative Humidity 5–95% Non-condensing Weight 9.5 oz.
CE
UL
See Compliance Table at http://www.heapg.com/Support/compliance.htm
AC Input /AC Output
Module
HE800DIQ722 / HE-DIQ722*
120 VAC In, Positive Logic
3A Relay Out
* HE- denotes plastic case.
