CONTENTS QUICK REFERENCE GUIDE PROGRAMME CHART PREPARING THE LAUNDRY SELECTING A PROGRAMME AND OPTIONS STARTING AND COMPLETING A PROGRAMME CHANGING A PROGRAMME INTERRUPTING A PROGRAMME DAILY MAINTENANCE AND CLEANING INSTRUCTIONS FOR USE BOOKLET 12 BEFORE USING THE DRYER / CONNECTIONS PAGE 13 PRECAUTIONS AND GENERAL RECOMMENDATIONS PAGE 14 DESCRIPTION OF THE DRYER PAGE 15 DRAINAGE SYSTEM PAGE 16 DOOR REVERSIBILITY / CHILD SAFETY LOCK PAGE 17 HEAT EXCHANGER PAGE 18 TROUBLESHOOTING GUIDE /
BEFORE USING THE DRYER / CONNECTIONS 1. Removing the packaging and check • After unpacking, make sure that the dryer is undamaged. If in doubt, do not use the dryer. Contact After-Sales Service or your local retailer. • Keep the packaging materials (plastic bags, polystyrene parts, etc.) out of reach of children, as they are potentially dangerous. • Remove the protective foil from the control panel. 2.
PRECAUTIONS AND GENERAL RECOMMENDATIONS 1. Packing The packing box may be fully recycled as confirmed by the recycling symbol . 2. Energy saving tips • Always dry a full load: depending on the type of laundry and the programme/drying time. • By preference use the maximum spin speed allowed by your washing machine, since draining the water mechanically requires less energy. You will save time and energy when running your drying cycle. • Do not overdry the laundry.
DESCRIPTION OF THE DRYER A. Work top. B1. Water Container bottom version or B2. Water Container top version. C. Contact pin. D. Door: To open the door: pull the handle. To close the door: push gently until closed. E. Filter. F. Child Safety Lock. G. Button for heat exchanger flap opening. H. Heat exchanger. A B2 G C F E D H B1 Reminder - Maintenance and Cleaning Clean the lint filter at the end of every drying cycle.
DRAINAGE SYSTEM For water container top only B To avoid having to empty the water container at the end of each cycle, the condensation water can be drained away. Note: Normally the drain hose is not supplied; the accessory AMH 883 kit, available at your dealer or our After Sales Service, should be used. The connection for direct draining is at the rear of the dryer. A. Place an absorbent cloth underneath to collect water spillage. B.
DOOR REVERSIBILITY / CHILD SAFETY LOCK Door Reversibility C A. Unplug the dryer. B. Open the door. C. Using a spanner, turn the contact pin in the upper part of the door by 90° and remove it. D. Unscrew the 2 screws of the door hinge and remove the door. E. Removing the door lock: Unscrew the 2 screws above and below the door lock system. Lift the door lock from the bottom, sliding it upwards about 1.5 cm, and remove it. F. Reverse the door: Fasten the door on the desired side with the 2 screws. G.
HEAT EXCHANGER Before cleaning or carrying out maintenance, switch off the dryer. Clean the heat exchanger at least every three months, proceeding as follows: A A. Open the door and press the heat exchanger flap button on the bottom of the door entrance. B. The heat exchanger flap opens. C. Fold the heat exchanger handle upwards to the horizontal position and remove the heat exchanger. D. Clean the heat exchanger under running water by turning it around to reach all sides. E.
TROUBLESHOOTING GUIDE / AFTER-SALES SERVICE Troubleshooting Guide After-Sales Service If a fault occurs, before contacting our AfterSales Service, make the following checks to try and remedy the problem: If, after carrying out the above checks the malfunction persists or appears again, turn the dryer off and call our After-Sales Service (refer to guarantee).
