Where used: 2 screws that secure the display bezel to the display on computers equipped with
BrightView display assemblies
Phillips PM3.0×3.5 screw
Color Quantity Length Thread Head diameter
Silver 4 3.5 mm 3.0 mm 4.8 mm
Where used: 4 screws that secure the hard drive bracket to the hard drive
134 Chapter 7 Screw listing
