QuickSpecs HP Compaq Tablet PC TC1100 Overview 1. 2. 3. 4. 5. 6. 7. Pen Tip Pen Button Pen Barrel Pen Tether Eyelet Battery Bay Power Switch Mobile Keyboard (attached) 8. 9. 10. 11. 12. 13. AC Adapter Light Battery Light Wireless LAN/Bluetooth Activity Light Tablet PC Input Panel Launch Journal Launch Button Rotate Button 1. 2. 3. 4. 5. 6. Integrated Antenna Power Switch Power/Standby Light Display Toggle (F4) Button Windows Security Button (CTRL+ALT+DEL) Jog Dial 7. 8. 9. 10. 11. 12.
QuickSpecs HP Compaq Tablet PC TC1100 Overview 1. 2. 3. 4. 5. 6. AC Power Connector Integrated IR External Monitor Connector RJ-45 Network Jack RJ-11 Telephone Jack External Multibay Connector (USB 2.0) 7. 8. 9. 10. 11. 12. USB 2.0 Connector Secure Digital (SD) Slot PC Card Slot Keyboard Connector Antenna (not visible from outside of tablet PC) Integrated Bluetooth What's New Fast, Ultra Low Voltage Intel™ Pentium M 1.
QuickSpecs HP Compaq Tablet PC TC1100 Standard Features Processor and Chipset Ultra low Voltage Intel™ PentiumM 1.0GHz processor with 400MHz Front Side Bus and 1MB cache Ultra low Voltage Mobile Intel Celeron 800MHz processor with 400MHz Front Side Bus and 512KB cache Intel 855PM chipset Display Memory Internal 10.4-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal) NOTE: All products have at least 100 degree wide viewing angle.
QuickSpecs HP Compaq Tablet PC TC1100 Standard Features PC Card Slots One Type II PC Card Slot that supports both 32-bit CardBus and 16-bit PCMCIA Cards Removable Media One Secure Digital (SD) slot Storage Internal Hard Drive 30GB , 40GB (4200rpm) or 60GB (5400rpm) SMART Hard drives NOTE: External MultiBay or Tablet PC Docking Station required for MultiBay drives.
QuickSpecs HP Compaq Tablet PC TC1100 Standard Features Software Pre-installed Software HP Mobile Printing for Notebooks HP Help and Support (XP Only) Safety and Comfort Guide Adobe Acrobat® Reader v. 5.10 Microsoft Reader v. 2.5 Zinio Reader v.1.4 Sun Java 1.4 Windows Media Player 9 for XP HP Tablet PC Tour *Intervideo WinDVD Playback Software v. 5.
QuickSpecs HP Compaq Tablet PC TC1100 Standard Features Service and Support HP Services includes a One-Year or Three-year, Worldwide Limited Warranty, pick-up or carry-in (select countries) and tollfree 7 x 24 hardware technical phone support. NOTE: Battery-free digital pen with tether and 40W/Hr internal main rechargeable Lithium-Ion battery carry a one-year warranty. NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details. http://wwss1pro.compaq.
QuickSpecs HP Compaq Tablet PC TC1100 Options Memory 256MB 333MHz RAM Memory Upgrade DC389B 512MB 333MHz RAM Memory Upgrade DC390B 1GB 333MHz RAM Memory Upgrade DC890B NOTE: Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility.
QuickSpecs HP Compaq Tablet PC TC1100 Options Removable Storage 5GB PCMCIA Hard Drive DF928A USB Digital Drive with 128MB Useful Accessories Carrying Cases DL702A SD Card Memory (128MB FA135A#AC3 SD Card Memory (256MB) FA136A#AC3 SD Card Memory (512MB) FA184A#AC3 Tablet PC Executive Slim-line Portfolio 310616-B25 Tablet PC Executive Workstation Portfolio 303177-B25 HP Entry Value DL617A Top Load Nylon DC915A Sport Backpack DG102A Executive Nylon DC916A Executive Leather DC917A D
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications System Unit Dimensions (H x W x D) 10.4-inch TFT panel display 10.8 x 8.5 x 0.8 in (27.4 x 21.6 x 2.0 cm) Weight Approximate 3.1 lb (1.4 kg) Tablet PC only 4 lb (1.8 kg) Tablet PC with keyboard Stand-Alone Power Requirements Nominal Operating Voltage 14.
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications Internal Lithium-Ion Battery Pack Weight 0.65 lb (0.30 kg) Cells 6-cell Lithium-Ion Energy Voltage 11.1 V Amp-hour capacity 3.6Ah Watt-hour capacity 40Wh Operating (Charging) 32° to 104° F (0° to 40° C) Operating (Discharging) 14° to 122° F (-10° to 50° C) Non-operating -4° to 140° F (-20° to 60° C) System in OFF mode or Standby 3 hours System ON (depending of system power consumption) 3 to 5 hours Dimensions (Length) 5.
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications MultiBay CD-RW Drive (optional) MultiBay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in (1.27 x 13.25 x 12.61 cm) Weight 0.74 lb (0.34 kg) Center Hole Diameter 0.59 in (1.5 cm) Disk Diameter 12 cm/8 cm Disk Thickness 0.047 in (1.2 mm) Track Pitch 0.74 µm Access Times (typical reads, including settling) Random < 150 ms Full-Stroke < 225 ms Audio Output Level Line-out 0.
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications MultiBay 24X CD-ROM Drive (optional) MultiBay Drive Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in (1.27 x 13.25 x 12.61 cm) Weight 0.50 lb (0.23 kg) Applicable Disk CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I ready (Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single and Multi-session), CDExtra, Video CD, CD-WO (fixed packets only), CD-Bridge Center Hole Diameter 0.
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications Internal MDC 56K (V.90/V.92) (Modem Specifications) Modem Device Driver Name Data Mode Capabilities V.92/ V.90 (a-law, mu-law) V.8bis V.80 V.44, V42.bis, MNP5 (Compression) V.42 (LAPM, MNP2-4) (Error Correction) V.34 (file date: 10/96) Optional symbol rates: 2800, 3429 Asymmetric Symbol rates Synchronous primary channel data signaling rates: 33600, 31200 Automatic rate re-negotiation V.32bis V.32 V.23 V.22bis V.22 V.
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications HP W500 802.11a/b/g Wireless LAN Standards WLAN (available as a special configuration) IEEE 802 Part 11a (802.11a) IEEE 802. Part 11b (802.11b) IEEE 802. Part 11g (802.11g) Interoperability Wi-Fi certified (details available at www.hp.com/go/WLAN) Frequency Band 2.4 and 5 GHz Data Rates 802.11a; 6,9,12,18,24,36,48,54 Mbps 802.11b; 1,2,5.5,11 Mbps 802.
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications LED Activity LED Off - WLAN and Bluetooth Radio OFF; Solid Green LED - WLAN or Bluetooth Radio ON (please refer to your Tablet PC documentation to determine whether WLAN or Bluetooth is activated) Agency Approvals details at www.hp.com/go/WLAN *Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation) Intel Pro/Wireless 2100 802.
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications Configuration Utility Choice of Configuration Utility: Intel ProSet (required for Cisco Compatible Extensions support) Microsoft Windows XP Wireless Zero Configuration Utility NOTE: may also be compatible with certain third party software supplicants LED Activity LED Off - Radio OFF; Solid LED - Radio ON Agency Approvals details at www.hp.com/go/WLAN *Receiver sensitivity is measured at a packet error rate of 8% for 802.
QuickSpecs HP Compaq Tablet PC TC1100 Technical Specifications File Transfer: Transfer File and directory browsing and navigation on another Bluetooth device. File copying Object manipulation - including add, delete, create new folders etc.
