HP Notebook PC (Intel) * Models: 15-ay000 - 15-ay099 HP 250 G5 Notebook PC HP 256 G5 Notebook PC - Maintenance and Service Guide
Table Of Contents
- Product description
- HP Notebook PC; Intel 7th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 7th generation Core and Pentium/Celeron processors; touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; touch models
- HP 250/256 G5 Notebook PC models
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures preliminary requirements
- Removal and replacement procedures for Customer Self-Repair parts
- Removal and replacement procedures for Authorized Service Provider parts
- Using Setup Utility (BIOS) in Windows 7
- Using Setup Utility (BIOS) in Windows 10
- Backing up, restoring, and recovering in Windows 7
- Backing up, restoring, and recovering in Windows 10
- Using HP PC Hardware Diagnostics (UEFI)
- Specifications
- Statement of memory volatility
- Power cord set requirements
- Recycling
- Index
Category Description Dis 7th
M1-70
Dis 7th
M1-30
UMA 7th
Gen Core
Dis Pent/
Celeron
UMA
Pent/
Celeron
SSHD conguration:
●
1-TB, 5400-rpm + 8GB NAND Hybrid hard drive,
9.5mm
M.2 SATA-3 congurations:
●
256 GB
●
128 GB
Optical drive Fixed, serial ATA, 9.5-mm tray load
DVD+/-RW Double-Layer SuperMulti
Supports zero power optical drive
Supports M-disc
Supports conguration without optical drive
√ √ √ √ √
Webcam/mi
c
HP TrueVision HD: Full HD camera - activity LED, USB
2.0, BSI sensor, f2.0, 720p by 30 frames per second
HP Webcam– 640 x 480 by 24 frames per second
Single digital microphone
HP Noise Cancellation enabled
√ √ √ √ √
HP TrueVision HD IR: Full HD camera - activity LED, 2x
IR, USB 2.0, BSI sensor, 1080p by 30 frames per
second
√ √ √ √
Audio DTS Studio Sound
Dual speakers
√ √ √ √ √
Ethernet Integrated 10/100 network interface card (NIC) √ √ √ √ √
Wireless
Network
Integrated wireless options with single antenna (M.
2/PCIe):
Compatible with Miracast-certied devices
Support for the following WLAN formats:
●
Realtek RTL8188EE-VJ 802.11b/g/n 1x1 Wi-Fi
Adapter
●
Realtek RTL8723BE-VB 802.11b/g/n 1x1 Wi-Fi +
BT4.0 Combo Adapter
√ √ √ √ √
Integrated wireless options with dual antennas (M.
2/PCIe):
Compatible with Miracast-certied devices
Support for the following WLAN formats:
●
Intel Dual Band Wireless-AC 3168 802.11 ac 1x1
WiFi + BT 4.2 Combo
√ √ √ √ √
External
media card
HP Multi-Format Digital Media Reader
Support SD/SDHC/SDXC
Push-Pull Insertion/Removal
√ √ √ √ √
HP Notebook PC; Intel 7th generation and Pentium/Celeron processors; non-touch models 3
