HP Notebook PC (Intel) * Models: 15-ay000 - 15-ay099 HP 250 G5 Notebook PC HP 256 G5 Notebook PC - Maintenance and Service Guide
Table Of Contents
- Product description
- HP Notebook PC; Intel 7th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 7th generation Core and Pentium/Celeron processors; touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; touch models
- HP 250/256 G5 Notebook PC models
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures preliminary requirements
- Removal and replacement procedures for Customer Self-Repair parts
- Removal and replacement procedures for Authorized Service Provider parts
- Using Setup Utility (BIOS) in Windows 7
- Using Setup Utility (BIOS) in Windows 10
- Backing up, restoring, and recovering in Windows 7
- Backing up, restoring, and recovering in Windows 10
- Using HP PC Hardware Diagnostics (UEFI)
- Specifications
- Statement of memory volatility
- Power cord set requirements
- Recycling
- Index
Category Description UMA 6th
Gen Core
UMA 5th
Gen Core
UMA Pentium/
Celeron
Intel Pentium® N3710 (1.6-GHz, turbo up to 2.56 GHz, 2-MB L3
cache, 1600-MHz, quad, 6W)
√
Intel Pentium® N3160 (1.6-GHz, turbo up to 2.24 GHz, 2-MB L3
cache, 1600-MHz, quad, 6W)
√
Chipset Intel Skylake U 1-chip series √
Intel Broadwell-U 1-chip BGA √
Intel Braswell √
Graphics Internal graphics
Intel HD Graphics 520 (Intel Skylake U series)
√
Intel HD Graphics 5500 (Intel Broadwell U series) √
Intel HD Graphics (Intel Braswell series √
Support HD Decode, DX12, HDMI, and PX7 √ √ √
Panel 39.6-cm (15.6-in); Touch-on Panel (TOP); High-denition (HD), white
light-emitting diode (WLED), SVA, BrightView (1366×768) display,
slim 3.2 mm, eDP; typical brightness: 200 nits
√ √ √
Memory Two non-customer-accessible/upgradable memory module slots
(Intel Core processors)
DDR4-2133 dual channel support
Supports up to 12 GB of system RAM in the following congurations:
●
12288-MB total system memory (8192×1) + (4096×1) [6th
generation Intel Core models only]
●
8192-MB total system memory (8192×1) or (4096×2)
●
6144-MB total system memory (4096×1) + (2048×1)
●
4096-MB total system memory (4096×1) or (2048×2)
●
2048-MB total system memory (2048×1)
√
Two non-customer-accessible/upgradable memory module slots
DDR3L-1600 dual channel support
√
One non-customer-accessible/upgradable memory module slot
DDR3L-1600 single channel support
√
Supports up to 12 GB of system RAM in the following congurations:
●
12288-MB total system memory (8192×1) + (4096×1) [5th
generation Intel Core models only]
●
8192-MB total system memory (8192×1) or (4096×2)
●
6144-MB total system memory (4096×1) + (2048×1)
●
4096-MB total system memory (4096×1)
●
2048-MB total system memory (2048×1)
√
Supports up to 8 GB of system RAM in the following congurations:
●
8192-MB total system memory (8192×1)
√
HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; touch models 13
