HP Notebook PC (Intel) * Models: 15-ay000 - 15-ay099 HP 250 G5 Notebook PC HP 256 G5 Notebook PC - Maintenance and Service Guide
Table Of Contents
- Product description
- HP Notebook PC; Intel 7th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 7th generation Core and Pentium/Celeron processors; touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; touch models
- HP 250/256 G5 Notebook PC models
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures preliminary requirements
- Removal and replacement procedures for Customer Self-Repair parts
- Removal and replacement procedures for Authorized Service Provider parts
- Using Setup Utility (BIOS) in Windows 7
- Using Setup Utility (BIOS) in Windows 10
- Backing up, restoring, and recovering in Windows 7
- Backing up, restoring, and recovering in Windows 10
- Using HP PC Hardware Diagnostics (UEFI)
- Specifications
- Statement of memory volatility
- Power cord set requirements
- Recycling
- Index
Item Component Spare part
number
(1) Display assembly (touch or non-touch)
NOTE: For display assembly spare part information, see Display assembly subcomponents
on page 38.
not spared
(2) Top cover/keyboard
NOTE: For a detailed list of keyboard country codes, see Top cover/keyboard on page 86.
For use in HP Notebook PC models:
●
Turbo silver 855022-xx1
●
White silver 855023-xx1
●
Red 855024-xx1
●
Teal 855025-xx1
●
Noble blue 855026-xx1
●
Realtree Xtra 864544-xx1
●
Iris purple 901746-xx1
●
Powder blue 908028-xx1
●
Soft lilac 908029-xx1
●
Minty green 908030-xx1
For use in HP Notebook PC and HP 250/256 G5 Notebook PC models:
●
Black 855027-xx1
●
Silver 905891-xx1
Top cover/keyboard for use in HP 250/256 G5 Notebook PC models:
Black for use in Canada 902973-DB1
(3) Touchpad button board (includes bracket and cables) 855011-001
(4) Power button board (includes cable) 855012-001
(5) Speakers (includes left and right speakers and cable) 813965-001
(6) System board (includes replacement thermal materials)
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 10 operating system
For use in HP Notebook models (Discrete graphics memory; non-touch screen):
●
Intel Core i7-7500U processor and 4 GB of discrete graphics memory (R7M1-70) 903786-xx1
●
Intel Core i7-7500U processor and 2 GB of discrete graphics memory (R7M1-70) 903787-xx1
●
Intel Core i7-6500U processor and 4 GB of discrete graphics memory (R7M1-70) 854932-xx1
●
Intel Core i7-6500U processor and 2 GB of discrete graphics memory (R5M1-30) 854933-xx1
●
Intel Core i7-6500U processor and 2 GB of discrete graphics memory (R7M1-70) 858868-xx1
32 Chapter 3 Illustrated parts catalog
