HP Notebook PC (Intel) * Models: 15-ay000 - 15-ay099 HP 250 G5 Notebook PC HP 256 G5 Notebook PC - Maintenance and Service Guide
Table Of Contents
- Product description
- HP Notebook PC; Intel 7th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 7th generation Core and Pentium/Celeron processors; touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; touch models
- HP 250/256 G5 Notebook PC models
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures preliminary requirements
- Removal and replacement procedures for Customer Self-Repair parts
- Removal and replacement procedures for Authorized Service Provider parts
- Using Setup Utility (BIOS) in Windows 7
- Using Setup Utility (BIOS) in Windows 10
- Backing up, restoring, and recovering in Windows 7
- Backing up, restoring, and recovering in Windows 10
- Using HP PC Hardware Diagnostics (UEFI)
- Specifications
- Statement of memory volatility
- Power cord set requirements
- Recycling
- Index
Item Component Spare part
number
Realtek RTL8188EE-VJ 802.11b/g/n 1x1 Wi-Fi Adapter 857334-855
Realtek RTL8723BE 802.11b/g/n 1x1 Wi-Fi + BT4.0 Combo Adapter 855106-855
Intel Dual Band Wireless-AC 3168 802.11 ac 1x1 WiFi + BT 4.2 Combo Adapter 863934-855
Heat sink assembly (includes replacement thermal materials)
(10) For use in models with discrete graphics memory and 5th or 6th generation Intel Core processors 815238-001
For use in models with discrete graphics memory and 6th generation Intel Pentium or Celeron
processors
816604-001
(11) For use in models with UMA graphics memory and 5th or 6th generation Intel Core processors 815237-001
For use in models with UMA graphics and 6th generation Intel Pentium or Celeron processors 854954-001
For use in models with discrete graphics memory and 7th generation Intel processors 903806-001
For use in models with UMA graphics memory and 7th generation Intel processors 903807-001
(12) Power connector cable 813945-011
(13) Solid-state drive board 850946-001
(14) Solid-state drive, M.2 (not illustrated)
256 GB 865902-002
128 GB, for use in HP Notebook PC models 827560-021
128 GB, for use in HP 250/256 G5 Notebook PC models 861334-001
256 GB, for use in HP 250/256 G5 Notebook PC models 861335-001
(15) Hard drive connector board 817878-001
(16) Hard drive (does not include bracket, connector board, or cable)
NOTE: For HP Notebook models, the hard drive cable is available using spare part number 855003-001.
For HP 250/256 G5 models, the hard drive brackets and cable are available in the Hard Drive Hardware Kit, spare part
number 859515-001 (ETB), and 859516-001 (non-ETB).
HP Notebook PC models:
●
2-TB, 5400-rpm, hybrid 8 GB SSD, 9.5 mm 801808-005
HP Notebook PC and HP 250/256 G5 Notebook PC models:
●
1-TB, 5400-rpm, hybrid 8 GB SSD 731999-005
●
1-TB, 5400-rpm, 2.5-inch 778192-005
●
1-TB, 5400-rpm, 2.5-inch (for use in India) 676423-855
●
500-GB, 5400-rpm, 7-mm 778186-005
HP 250/256 G5 Notebook PC models:
●
500-GB, 7200-rpm, 7-mm 703267-005
(17) USB board (includes cable) 855010-001
(18) Optical drive board 855007-001
(19) Fan 813946-001
Computer major components 35
