Display assembly subcomponents
Item Component Spare part number
(1) Display bezel (includes Mylar screw covers) 855000-001
(2) Raw display panel (39.6-cm [15.6-in])
For use in HP Notebook PC models:
●
FHD, non-touch screen (anti glare) 798933-007
●
HD, non-touch screen (anti glare) 909185-001
●
HD, touch screen (BrightView) 809612-010
●
HD, non-touch screen (BrightView) 847654-003
●
FHD, non-touch (BrightView) 842463-006
For use in HP 250/256 G5 Notebook PC models:
●
FHD 864124-001
●
HD 864125-001
(3) Hinges (left and right) 855006-001
(4) Display cable (includes display panel cable and webcam/microphone cable)
Non-touch screen 813943-001
