HP Notebook PC (Intel) * Models: 15-ay000 - 15-ay099 HP 250 G5 Notebook PC HP 256 G5 Notebook PC - Maintenance and Service Guide
Table Of Contents
- Product description
- HP Notebook PC; Intel 7th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; non-touch models
- HP Notebook PC; Intel 7th generation Core and Pentium/Celeron processors; touch models
- HP Notebook PC; Intel 5th and 6th generation and Pentium/Celeron processors; touch models
- HP 250/256 G5 Notebook PC models
- External component identification
- Illustrated parts catalog
- Removal and replacement procedures preliminary requirements
- Removal and replacement procedures for Customer Self-Repair parts
- Removal and replacement procedures for Authorized Service Provider parts
- Using Setup Utility (BIOS) in Windows 7
- Using Setup Utility (BIOS) in Windows 10
- Backing up, restoring, and recovering in Windows 7
- Backing up, restoring, and recovering in Windows 10
- Using HP PC Hardware Diagnostics (UEFI)
- Specifications
- Statement of memory volatility
- Power cord set requirements
- Recycling
- Index
Item Component Spare part number
Touch screen 813944-001
(5) Webcam/microphone module
For use in HP Notebook PC models:
●
HD 709372-030
●
VGA 766523-019
For use in HP Notebook PC and HP 250/256 G5 Notebook PC models:
●
HD 861336-001
●
VGA 861337-001
(6) Antenna (includes wireless antenna cable and transceiver)
Single 854985-001
Dual 854986-001
(7) Display enclosure:
For use in Notebook PC models:
●
Black models 854992-001
●
Turbo silver models 854987-001
●
Red models 854989-001
●
White silver models 854988-001
●
Noble blue models 854991-001
●
Teal models 854990-001
●
Realtree Xtra models 864542-001
●
Iris purple models 901745-001
●
Powder blue models 908025-001
●
Soft lilac models 908026-001
●
Minty green models 908027-001
For use in HP 250/256 G5 Notebook PC models:
●
Black models 859511-001
●
Silver models 905913-001
Display assembly subcomponents 39
