Mass storage devices
Item Component Spare part number
(1) Optical drive (DVD+/-RW Double-Layer SuperMulti; includes bracket and bezel)
For use in all models 858505-001
For use in HP 250/256 G5 Notebook PC models 908491-001
(2) Solid-state drive, M.2, 128 GB
256 GB 865902-002
128 GB (for use in HP Notebook PC models) 827560-021
128 GB (for use in HP 250/256 G5 Notebook PC models) 861334-001
256 GB (for use in HP 250/256 G5 Notebook PC models) 861335-001
(3) Hard drive, SATA; does not include brackets, connector board, or cable):
For use in HP Notebook PC models:
●
2-TB, 5400-rpm, hybrid 8 GB SSD, 9.5 mm 801808-005
40 Chapter 3 Illustrated parts catalog
