System board
NOTE: The system board spare part kit includes replacement thermal materials.
Description Spare part number
System board (includes replacement thermal materials):
All system boards use the following part numbers:
xxxxxx-001: Windows 7 or non-Windows operating systems
xxxxxx-601: Windows 10 operating system
For use in HP Notebook models (Discrete graphics memory; non-touch screen):
●
Intel Core i7-7500U processor and 4 GB of discrete graphics memory (R7M1-70) 903786-xx1
●
Intel Core i7-7500U processor and 2 GB of discrete graphics memory (R7M1-70) 903787-xx1
●
Intel Core i7-6500U processor and 4 GB of discrete graphics memory (R7M1-70) 854932-xx1
●
Intel Core i7-6500U processor and 2 GB of discrete graphics memory (R5M1-30) 854933-xx1
●
Intel Core i7-6500U processor and 2 GB of discrete graphics memory (R7M1-70) 858868-xx1
●
Intel Core i5-7200U processor and 4 GB of discrete graphics memory (R7M1-70) 903789-xx1
●
Intel Core i5-7200U processor and 4 GB of discrete graphics memory (R5M1-30) 903790-xx1
●
Intel Core i5-7200U processor and 2 GB of discrete graphics memory (R5M1-30) 903791-xx1
●
Intel Core i5-6200U processor and 4 GB of discrete graphics memory (R7M1-70) 854935-xx1
●
Intel Core i5-6200U processor and 4 GB of discrete graphics memory (R5M1-30) 858869-xx1
●
Intel Core i5-6200U processor and 2 GB of discrete graphics memory (R5M1-30) 854936-xx1
●
Intel Core i3-7100U processor and 2 GB of discrete graphics memory (R5M1-30) 903794-xx1
●
Intel Core i3-6100U processor and 2 GB of discrete graphics memory (R5M1-30) 854938-xx1
●
Intel Core i3-6006U processor and 2 GB of discrete graphics memory (R5M1-30) 909167-xx1
●
Intel Core i3-5005U processor and 2 GB of discrete graphics memory (R5M1-30) 854940-xx1
●
Intel Pentium N4200 processor and 2 GB of discrete graphics memory (R5M1-30) 903797-xx1
●
Intel Pentium N3710 processor and 2 GB of discrete graphics memory (R5M1-30) 854942-xx1
For use in HP Notebook models (UMA graphics memory; non-touch screen)::
●
Intel Core i7-7500U processor 903788-001
●
Intel Core i7-6500U processor 854934-xx1
●
Intel Core i5-7200U processor 903792-001
●
Intel Core i5-6200U processor 854937-xx1
●
Intel Core i3-7100U processor 903795-001
●
Intel Core i3-6100U processor 854939-xx1
●
Intel Core i3-6006U processor 909168-xx1
●
Intel Core i3-5005U processor 854941-xx1
●
Intel Core i3-5005U processor, ESD 855825-xx1
Component replacement procedures 73
