Top cover/keyboard
The top cover/keyboard spare part remains after all other spare parts have been removed.
The top cover/keyboard spare part kit includes the keyboard, keyboard cable and the keyboard backlight
cable.
In this section, the rst table provides the main spare part number for the keyboard. The second table
provides the country codes.
NOTE: All top cover/keyboard spare part kits include TouchPad.
Description Spare part number
Top cover/keyboard for use in HP Notebook PC models:
Turbo silver models 855022-xx1
White silver models 855023-xx1
Red models 855024-xx1
Teal models 855025-xx1
Noble blue models 855026-xx1
Realtree Xtra models 864544-xx1
Iris purple models 901746-xx1
Powder blue models 908028-xx1
Soft lilac models 908029-xx1
Minty green models 908030-xx1
Top cover/keyboard for use in HP Notebook PC and HP 250/256 G5 Notebook PC models:
Black models 855027-xx1
Silver models 905891-xx1
Top cover/keyboard for use in HP 250/256 G5 Notebook PC models:
Black models for use in Canada 902973-DB1
For use in country
or region
Spare
part
number
For use in country
or region
Spare
part
number
For use in country
or region
Spare
part
number
Belgium -A41 Greece -151 Saudi Arabia -171
Bulgaria -261 Hungary -211 Slovenia -BA1
Canada -DB1 Japan -291 South Korea -AD1
Czech Republic
and Slovakia
-FL1 The Netherlands -B31 Spain -071
Denmark, Finland, and
Norway
-DH1 Portugal -131 Switzerland -BG1
86 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
