Intel Unite Solution - Enterprise Deployment Guide

Intel Unite® Solution Enterprise Deployment Guide v3.1.7 40 of 83

8.2.2 Icon/ links nomenclature

Through the Admin Portal, you will consistently see the following icons or links:

Edit

View Details

View Devices

Delete

Dialog box containing information about a specific value

By placing the cursor over the icon you will be able to see the information pertaining to the respective item.

8.3 Devices page

The Devices page contains all devices currently in the database. You can select a specific device and View,

Edit, Update or Remove accordingly.

On the Devices page you will find:

 System FQDN is the fully qualified domain name of the Client/Hub

 Profile has configuration settings that are applied to the device

 Group is the name of the group that a device has been assigned to

 Status shows if the device is active - ON (green) - or inactive - OFF ( gray) -

 Last Check-in is the last time the device checked in with the server

 Details: by clicking on the View Details link, the window Client Properties will be displayed showing

the system properties and its metadata. Some of the keys under Client Properties are:

 CertificateHash

 ClientHostName

 IPAddress

 IsRoomMode

 SevicePort

To know more about valid values for each key go to section Profile Configuration for detailed

information about keys and corresponding values.
