Component Description
2. Select My PC, select the Specications tab, and then select User Guides.
Top
TouchPad
Component Description
(1) Pointing stick (select products only) Moves the pointer and selects or activates items on the screen.
(2) Left pointing stick button (select products only) Functions like the left button on an external mouse.
(3) TouchPad light
●
On: The TouchPad is o.
●
O: The TouchPad is on.
(4) TouchPad zone Reads your nger gestures to move the pointer or activate
items on the screen.
(5) Left TouchPad button Functions like the left button on an external mouse.
(6) Right pointing stick button (select products
only)
Functions like the right button on an external mouse.
(7) Right TouchPad button Functions like the right button on an external mouse.
Top 11
