State Changes Monitors state
changes
Unit: error(s)
Time Base: minute
Low: 1
High: 5
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_rang
e
In_range
Transmit
Performance
Monitors the
transmit rate, by
percentage
Unit: percentage
Time Base: minute
Low: 0
High: 100
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Informative
Informative
Informative
Invalid CRC
Count
Monitors the
number of CRC
errors
Unit: error(s)
Time Base: minute
Low: 1
High: 5
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_rang
e
In_range
Invalid
Transmission
Word
Monitors the
number of
invalid words
transmitted
Unit: error(s)
Time Base: minute
Low: 1
High: 5
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_rang
e
In_range
Link Failure Count Monitors the
number of link
failures
Unit: error(s)
Time Base: minute
Low: 1
High: 5
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_rang
e
In_range
Loss of Signal
Count
Monitors the
number of
signal loss
errors
Unit: error(s)
Time Base: minute
Low: 1
High: 5
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_rang
e
In_range
Primitive
Sequence
Protocol Error
Monitors the
number of
primitive
sequence errors
Unit: error(s)
Time Base: minute
Low: 1
High: 5
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_rang
e
In_range
Table 28 F/FL-Port class threshold defaults (continued)
Area Description Default Threshold
Settings
Default Alarm
Settings
Threshold
State
