HP StorageWorks Fabric OS 5.0.0 Fabric Watch User Guide (AA-RW1TA-TE, May 2005)

An introduction to Fabric Watch18
Environment class
Table 2 provides default settings for areas in the Environment class. These defaults are
hardware-dependent. Check the appropriate hardware reference manual for differences in
environmental requirements.
Table 2 Environment class threshold defaults
Area Description Default threshold
settings
Default alarm
settings
Threshold state
Fan Monitors switch fan
speed in RPMs
Unit: RPM
Time Base: none
HP StorageWorks SAN
Switch 2/8V and
Switch 2/16V
Low: 4500
High: 11000
Buffer: 3
HP StorageWorks SAN
Switch 2/32
Low: 2600
High: 10000
Buffer: 3
HP StorageWorks SAN
Switch 4/32
Low: 3000
High: 12000
Buffer: 3
HP StorageWorks Core
Switch 2/64
Low: 2600
High: 3400
Buffer: 3
HP StorageWorks Core
Switch 2/128
Low: 1600
High: 3400
Buffer: 3
Changed: 0
Above: 3
Below: 3
In-Between: 1
Informative
Out_of_range
Out_of_range
In_range
Power Supply Monitors power
supply condition
Unit: 1/0 (OK/FAULTY)
Time Base: none
The default threshold
settings for all platforms
are:
Low: 1
High: 0
Buffer:0
Changed: 0
Below: 3
Above: 3
In-Between: 0
Informative
Out_of_range
In_range
Informative
