Configuring Fabric Watch58

The next two screens show how to change the threshold boundary level to custom so that the

new custom value of 80 is the new trigger point. This example shows how to apply the custom

value; unless you apply the value, it does not take effect.

Table 15 describes the event behavior of each element in the Threshold Boundary menu.

1 : change behavior type 11 : change threshold alarm level

2 : change behavior interval 12 : change changed alarm

3 : change threshold boundary level 13 : change below alarm

4 : change custom unit 14 : change above alarm

5 : change custom time base 15 : change inBetween alarm

6 : change custom low 16 : apply threshold alarm changes

7 : change custom high 17 : cancel threshold alarm changes

8 : change custom buffer 18 : return to previous page

9 : apply threshold boundary changes

10 : cancel threshold boundary changes

Select choice => : (1..18) [18] 3

1 : Default

2 : custom

Enter boundary level type => : (1..2) [1] 2

Index ThresholdName BehaviorType BehaviorInt

8 eportRXPerf008 Triggered 1

17 eportRXPerf017 Triggered 1

26 eportRXPerf026 Triggered 1

27 eportRXPerf027 Triggered 1

28 eportRXPerf028 Triggered 1

29 eportRXPerf029 Triggered 1

Threshold boundary level is set at : Custom
