Table 25 provides default settings for areas in the End-to-End Performance Monitor class.
Port class
Table 26 provides default settings for areas in the Port class.
Table 25 End-to-End performance monitor class threshold defaults
Area Description Default threshold
settings
Default alarm
settings
Threshold
state
End-to-End Invalid
CRC Count
Monitors the
number of CRC
errors between a
SID_DID pair in a
port
Unit: errors
Time Base: none
Low: 1
High: 10
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_range
In_range
End-to-End Receive
Performance
Monitors the
receiving traffic
between a
SID_DID pair in a
port
Unit: KB/sec
Time Base: none
Low: 0
High: 0
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Informative
Informative
End-to-End
Transmit
Performance
Monitors the
transmit traffic
between a
SID_DID pair in a
port
Unit: KB/sec
Time Base: none
Low: 0
High: 0
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Informative
Informative
Table 26 Port Class threshold defaults
Area Description Default threshold
settings
Default alarm
settings
Threshold
state
Invalid CRC
Count
Monitors the
number of CRC
errors
Unit: error(s)
Time Base: minute
Low: 1
High: 5
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_range
In_range
Invalid
Transmission
Word
Monitors the
number of
invalid words
transmitted
Unit: error(s)
Time Base: minute
Low: 0
High: 5
Buffer: 0
Changed: 0
Below: 0
Above: 0
In-Between: 0
Informative
Informative
Out_of_range
In_range
