Chapter 5 Problem Solving 218
Clearing Paper Jams
Clearing the Left Door (Fuser Area)
1 Open the left door. (If an optional output device is installed, first push it
away from the printer to access the left door.)
WARNING! Avoid touching the adjacent fusing area. It may be HOT.
2 Remove any jammed or damaged paper from this area by pulling it out of
the printer (A
).
3 Press down on the green tabs (B
) and carefully check for paper. Be sure to
remove all pieces of torn paper.
4 Close the left door. If an optional output device is installed, push it back
into place.
B
A
