Appendix B Control Panel Menus 463
EIO Menu
CFG LINK=NO NO
YES
NO: The 10/100Base-TX link configuration menu will not
be accessed.
YES: Allows you to access and manually set
10/100Base-TX link parameters.
! AUTO: (Default) The print server will automatically
configure itself to match the network’s link speed and
communication mode.
! 10T HALF: Sets 10 Mbps, Half-duplex operation on the
print server.
! 10T FULL: Sets 10 Mbps, Full-duplex operation on the
print server.
! 100TX HALF: Sets 100 Mbps, Half-duplex operation on
the print server.
! 100TX FULL: Sets 100 Mbps, Full-duplex operation on
the print server.
Item Values Explanation
