hp business inkjet

1100d

•1100dtn

before setup

• Windows: Install the printer software first.

Only connect the USB or parallel cable when

prompted.

• Network and Mac OS: Connect the

printer before installing the printer software.

przed instalacj

• System Windows: Najpierw zainstaluj

oprogramowanie drukarki. Gdy pojawi si

monit, podłcz tylko jeden kabel, USB lub

równoległy.

• Sieć i system Mac OS: Podłcz drukark

przed zainstalowaniem oprogramowania

drukarki.

instalací spust’te

• Windows: Nejprve nainstalujte software

tiskárny. Po výzv pipojte jen kabel USB

nebo paralelní kabel.

• Sít’ a Mac OS: Ped instalací softwaru

tiskárny pipojte tiskárnu.

telepítés eltt

• Windows: Elször a nyomtatószoftvert kell

telepíteni. Az USB vagy a párhuzamos

kábelt csak akkor csatlakoztassa, ha azt a

számítógép kéri.

• Hálózati és Mac OS: A nyomtatót a

nyomtatószoftver telepítése eltt kell

csatlakoztatni.

kurulumdan önce

• Windows: İlk olarak yazıcı yazılımını

yükleyin. USB veya paralel kabloyu yalnızca

istendiği zaman bağlayın.

• Ağ ve Mac OS: Yazıcı yazılımını

yüklemeden önce yazıcıyı bağlayın.

   

• Windows:  

  .

   

 , 

  USB  

.

•    Mac OS: 

   

 .

EMEA_90005.book Page 1 Wednesday, April 16, 2003 2:05 PM

getting started guide

przewodnik czynnoci

wstpnych

úvodní píručka

alapvet tudnivalók

kézikönyve

başlarken kılavuzu

вводное руководство



Summary of content (24 pages)

PAGE 1
EMEA_90005.book Page 1 Wednesday, April 16, 2003 2:05 PM hp business inkjet 1100d •1100dtn getting started guide przewodnik czynno ci wst pnych before setup • Windows: Install the printer software first. Only connect the USB or parallel cable when prompted. • Network and Mac OS: Connect the printer before installing the printer software. úvodní p íručka alapvet tudnivalók kézikönyve başlarken kılavuzu przed instalacj • System Windows: Najpierw zainstaluj oprogramowanie drukarki.
PAGE 2
EMEA_90005.book Page 1 Wednesday, April 16, 2003 2:05 PM Copyright Information © Copyright Hewlett-Packard Company 2003 All Rights Reserved. Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. Edition 1, 9/2003 Warranty The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with respect to this information.
PAGE 3
EMEA_90005.book Page 2 Wednesday, April 16, 2003 2:05 PM Informace o bezpečném použití výrobku Biztonsági információ Při používání tohoto výrobku vždy dodržujte základní bezpe cnostní opat rení tak, abyste snížili nebezpe čí úrazu ohn em nebo elektrickým proudem. A termék használatakor mindig kövesse az alapvető biztonsági óvintézkedéseket, a tűzből vagy az áramütésből származó sérülés veszélyének csökkentése érdekében.
PAGE 4
EMEA_90005.book Page 3 Wednesday, April 16, 2003 2:05 PM 1 1 2 10 3 7 4 5 9 8 6 Pусский Türkçe Magyar Česky Polski English 11 12 Step 1: Check the package contents.
PAGE 5
EMEA_90005.book Page 4 Wednesday, April 16, 2003 2:05 PM 2 4 3 3 2 1 5 7 6 Step 2: Remove the packing tape and materials. Remove all packing tape from the outside of the printer and the trays. Open the printing supplies cover and remove the tape from the inside of the printer. Step 3: Identify printer parts (front). 1) Output tray, 2) paper guides, 3) top cover, 4) control panel, 5) printing supplies cover, 6) Tray 1, 7) tray extension. Krok 2: Zdejmij taśmę i usuń materiały pakunkowe.
PAGE 6
EMEA_90005.book Page 5 Wednesday, April 16, 2003 2:05 PM 1 1 2 a b c 2 4 4 3 Identify control panel parts. 1) (power button), 2) printing supplies lights: a) printhead light, b) ink cartridge light, c) color indicator lights, 3) (cancel button), 4) (resume button). Identify printer parts (back). 1) Universal serial bus (USB) port, 2) slot for a parallel connector or print server, 3) power input, 4) slot for the auto-duplex unit. Zidentyfikuj części panelu sterowania.
PAGE 7
EMEA_90005.book Page 6 Wednesday, April 16, 2003 2:05 PM 5 4 Step 4: Install the auto-duplex unit. On the back of the printer, insert the auto-duplex unit until it clicks. Step 5: Install Tray 2 (HP Business Inkjet 1100dtn). Set the printer on top of Tray 2. WARNING! Be careful to keep your fingers and hands clear of the bottom of the printer. Krok 4: Zainstaluj jednostkę automatycznego drukowania dwustronnego.
PAGE 8
EMEA_90005.book Page 7 Wednesday, April 16, 2003 2:05 PM 6 7 1 3 2 Pусский Türkçe Magyar Česky Polski English 1 Step 6: Connect the power cord. 1) Plug the power adapter into the printer. 2) Connect the power cord to the power adapter. 3) Plug the other end of the power cord into an alternating current (AC) power outlet. Note: Connect the printer to the computer only when prompted to do so during installation. Step 7: Load paper in the trays. 1) Pull the tray out of the printer.
PAGE 9
EMEA_90005.book Page 8 Wednesday, April 16, 2003 2:05 PM 6 3 5 4 3) For paper between 11 inches and 14 inches (356 mm and 279 mm) long, move the latch on the tray to the right; 4) then lower the front of the tray. 5) Slide the guides in the tray to adjust them for the size that you are loading. 6) Insert up to 150 sheets of paper into Tray 1 or 250 sheets of paper into Tray 2. Note: Tray 2 can be loaded only with plain paper.
PAGE 10
EMEA_90005.book Page 9 Wednesday, April 16, 2003 2:05 PM 8 1 7 8 Step 8: Install the ink cartridges. 1) Open the printing supplies cover. 2) Remove each ink cartridge from its package. CAUTION: Use only HP ink cartridges. Damage to the printer that results from modifying or refilling HP ink cartridges, or from using non-HP ink cartridges, is not covered under the warranty. 7) Ponownie zamocuj tacę odbiorczą (jeśli papier był ładowany do Podajnika 1). 8) Włóż ponownie podajnik do drukarki.
PAGE 11
EMEA_90005.book Page 10 Wednesday, April 16, 2003 2:05 PM 9 3 1 3 4 2 3) Align the arrow on each cartridge with the arrow on its color-coded slot, and then insert the cartridge into the slot. 4) To ensure proper contact, press down firmly on the cartridges until they snap into place. Note: All four ink cartridges must be correctly installed for the printer to work. Step 9: Turn the printer on and install the printheads. 1) Press the (power button) to turn on the printer.
PAGE 12
EMEA_90005.book Page 11 Wednesday, April 16, 2003 2:05 PM 5 4 8 6 Pусский Türkçe Magyar Česky Polski English 7 4) Remove the packing material from the printhead slot. 5) Remove each printhead from its package, and then remove the protective tape from each printhead. 6) Insert each printhead into its color-coded slot, and then press down firmly on each printhead to ensure proper contact. 7) Pull the printhead latch all the way forward and down. 8) Push the latch toward the back of the printer.
PAGE 13
EMEA_90005.book Page 12 Wednesday, April 16, 2003 2:05 PM 2 1 9) Close the printing supplies cover. The printer aligns the printheads and prints two alignment pages. This process takes approximately 5 minutes. If the printer prints the two alignment pages, go to Step 10. If it does not print, follow these steps. 1) Check that the power cord is connected firmly. 2) Check that the printheads and ink cartridges are properly installed. 3) Check that the auto-duplex unit is installed.
PAGE 14
EMEA_90005.book Page 13 Wednesday, April 16, 2003 2:05 PM 10 5 Step 10: Install the print server (HP Business Inkjet 1100dtn) or parallel connector (HP Business Inkjet 1100d). • If using the USB connector, go to Step 11. Note: Do not connect the cable yet (occurs when you install the software). • For the HP Business Inkjet 1100dtn, remove the slot cover and insert the print server as shown until it clicks. Connect the network cable between the printer and the network.
PAGE 15
EMEA_90005.book Page 14 Wednesday, April 16, 2003 2:05 PM 11 • For the HP Business Inkjet 1100d, remove the slot cover and insert the parallel connector as shown until it clicks. Note: Do not connect the cable yet (occurs when you install the software). Step 11: Install the software. 1) If you are using the network connection, install the HP Jetdirect software to configure the print server. Otherwise, go to step 2 below.
PAGE 16
EMEA_90005.book Page 15 Wednesday, April 16, 2003 2:05 PM If using the USB ( ) or parallel ( ) connection, connect the cable (sold separately) when prompted during installation. (For parallel connection, remove the slot cover first.) Connect only a parallel cable or a USB cable—not both. Note: If you connected using a USB cable or parallel cable before you installed the software, see “Connecting the printer” in the onscreen user’s guide on the Starter CD to complete the installation.
PAGE 17
EMEA_90005.book Page 16 Wednesday, April 16, 2003 2:05 PM 13 Step 13: Register the printer. Register the printer to receive important support and technical information. If you did not register your printer while installing the software, you can register later at http://www.register.hp.com. Congratulations! Your printer is ready to use. For information about using the printer and troubleshooting, see the following resources: • onscreen user’s guide on the Starter CD.
PAGE 18
EMEA_90005.
PAGE 19
EMEA_90005.
PAGE 20
EMEA_90005.
PAGE 21
EMEA_90005.
PAGE 22
EMEA_90005.
PAGE 23
EMEA_90005.book Page 22 Wednesday, April 16, 2003 2:05 PM Положения ограниченной гарантии Hewlett-Packard Продукт HP Пределы ограниченной гарантии Программное обеспечение 1 год Дополнительные принадлежности 1 год картриджи 90 дней Периферийное оборудование принтера (см.
