Limitations and Restrictions

High CPU utilization can also occur with other conditions, such as when debug messages are logged at

a high rate to the console.

Use one of these workarounds:

• Disable logging to the console.

• Rate-limit logging messages to the console. (CSCsg91027)

• Remove the logging event spanning-tree interface configuration command from the interfaces.

Trunking

These are the trunking limitations:

• The switch treats frames received with mixed encapsulation (802.1Q and Inter-Switch Link [ISL])

as frames with FCS errors, increments the error counters, and causes the LED to blink amber. This

happens when an ISL-unaware device receives an ISL-encapsulated packet and forwards the frame

to an 802.1Q trunk interface. There is no workaround. (CSCdz33708)

• IP traffic with IP options set is sometimes leaked on a trunk port. For example, a trunk port is a

member of an IP multicast group in VLAN X but is not a member in VLAN Y. If VLAN Y is the

output interface for the multicast route entry assigned to the multicast group and an interface in

VLAN Y belongs to the same multicast group, the IP-option traffic received on an input VLAN

interface other than one in VLAN Y is sent on the trunk port in VLAN Y because the trunk port is

forwarding in VLAN Y, even though the port has no group membership in VLAN Y. There is no

workaround. (CSCdz42909)

• For trunk ports or access ports configured with 802.1Q tagging, inconsistent statistics might appear

in the show interfaces counters privileged EXEC command output. Valid 802.1Q frames of 64 to

66 bytes are correctly forwarded even though the port LED blinks amber, and the frames are not

counted on the interface statistics. There is no workaround. (CSCec35100)

VLAN

These are the VLAN limitations:

• If the number of VLANs times the number of trunk ports exceeds the recommended limit of 13,000,

the switch can fail. The workaround is to reduce the number of VLANs or trunks. (CSCeb31087)

• When dynamic ARP inspection is configured on a VLAN, and the ARP traffic on a port in the VLAN

is within the configured rate limit, the port might go into an error-disabled state. (CSCse06827)

Device Manager Limitations and Restrictions

These are the device manager limitations and restrictions:

• You cannot create and manage switch clusters through the device manager. To create and manage

switch clusters, use the CLI.

• When you are prompted to accept the security certificate and you click No, you only see a blank

screen, and the device manager does not launch.

The workaround is to click Yes when you are prompted to accept the certificate. (CSCef45718)
