Documentation Updates
Error Message DOT1X_SWITCH-5-ERR_VLAN_EQ_VVLAN: Data VLAN [dec] on port [chars]
cannot be equivalent to the Voice VLAN AuditSessionID [chars]
Explanation
An attempt was made to assign a data VLAN to an 802.1x port that is the same as the
voice VLAN. [dec] is the VLAN, the first [chars] is the port, and the second [chars] is the session ID.
Recommended Action Change either the voice VLAN or the 802.1x-assigned VLAN on the interface
so that they are not the same.
Error Message DOT1X_SWITCH-5-ERR_VLAN_INTERNAL: Attempt to assign internal VLAN
[dec] to 802.1x port [chars] AuditSessionID [chars]
Explanation
An attempt was made to assign an invalid VLAN to an 802.1x port. The VLAN specified
is used internally and cannot be assigned to this port. [dec] is the VLAN, the first [chars] is the port,
and the second [chars] is the session ID.
Recommended Action Assign a different VLAN.
Error Message DOT1X_SWITCH-5-ERR_VLAN_INVALID: Attempt to assign invalid VLAN [dec]
to 802.1x port [chars] AuditSessionID [chars]
Explanation
An attempt was made to assign an invalid VLAN to an 802.1x port. The VLAN specified
is out of range. [dec] is the VLAN, the first [chars] is the port, and the second [chars] is the session
ID.
Recommended Action Update the configuration to use a valid VLAN.
Error Message DOT1X_SWITCH-5-ERR_VLAN_NOT_FOUND: Attempt to assign non-existent or
shutdown VLAN [chars] to 802.1x port [chars] AuditSessionID [chars]
Explanation
An attempt was made to assign a VLAN to an 802.1x port, but the VLAN was not found
in the VLAN Trunking Protocol (VTP) database. [dec] is the VLAN, the first [chars] is the port, and
the second [chars] is the session ID.
Recommended Action Make sure the VLAN exists and is not shut down, or use another VLAN.
Error Message DOT1X_SWITCH-5-ERR_VLAN_ON_ROUTED_PORT: Attempt to assign VLAN [dec]
to routed 802.1x port [chars] AuditSessionID [chars]
Explanation
An attempt was made to assign a VLAN to a supplicant on a routed port, which is not
allowed. [dec] is the VLAN ID, the first [chars] is the port, and the second [chars] is the session ID.
Recommended Action Either disable the VLAN assignment, or change the port type to a nonrouted
port.
