Compaq ProLiant Cluster HA/F500 Enhanced Configuration Poster

Storage Subsystem
Storage Controllers
ProLiant
Servers
Host Bus
Adapters
Host Bus
Adapters
Host Bus
Adapters
Host Bus
Adapters
Fibre Channel
Switch
Fibre Channel Cables
Gigabit Interface
Converter-Shortwave
Connector
14. Install the latest Microsoft Service Pack.
15. Verify the cluster operation, node failover, and client
failover.
16. Set up the cluster groups and cluster resources.
Legal NoticeLegal Notice
Legal NoticeLegal Notice
Legal Notice
©2002 Compaq Information Technologies Group, L.P.
Compaq, the Compaq logo, ProLiant, and StorageWorks are trademarks of
Compaq Information Technologies Group, L.P. in the U.S. and/or other
countries. Microsoft, Windows, and Windows NT are trademarks of
Microsoft Corporation in the U.S. and/or other countries. All other product
names mentioned herein may be trademarks of their respective
companies.
Compaq shall not be liable for technical or editorial errors or omissions
contained herein. The information in this document is provided "as is"
without warranty of any kind and is subject to change without notice. The
warranties for Compaq products are set forth in the express limited
warranty statements accompanying such products. Nothing herein should
be construed as constituting an additional warranty.
MICROSOFT DATACENTER CONFIGURATION
ProLiant Cluster HA/F500 for MA8000
Enhanced Configuration
This Microsoft Windows 2000 Datacenter Server configuration
includes the following hardware components:
>>
>>
> Compaq ProLiant servers (supported servers can be found
at
ww
ww
w
ww
ww
w
ww
ww
w
.c.c
.c.c
.c
ompaq.compaq.c
ompaq.compaq.c
ompaq.c
om/highaom/higha
om/highaom/higha
om/higha
vv
vv
v
ailabilityailability
ailabilityailability
ailability)
>>
>>
> StorageWorks storage subsystem by Compaq
RA8000/MA8000/EMA12000/ESA12000/ESA16000
>>
>>
> Two 64-bit/33-MHz PCI to Fibre Channel (KGPSA-CB) or
FCA 2101 (LP952) HBAs in each server
>>
>>
> Two Fibre Channel SAN Switch 8/8-EL or
16/16-EL switches
>>
>>
> Two HSG80 controllers (storage controllers) in each
storage subsystem
IMPIMP
IMPIMP
IMP
OROR
OROR
OR
TT
TT
T
ANAN
ANAN
AN
TT
TT
T
::
::
: The interconnect and LAN cabling are not
illustrated in the Microsoft Datacenter configuration because
of the variety of possible slot, NIC, and cabling configurations.
CLUSTER INSTALLATION OVERVIEW
1. Set up the ProLiant servers by installing and configuring
Microsoft Windows 2000 Datacenter Server.
2. Install the dedicated interconnect.
3. Set up the storage subsystem.
a. Configure the storage controllers.
b. Connect cables from the Fibre Channel switches to
the storage subsystem.
4. Install and configure two HBAs in each server.
5. Install SWCC.
6. Configure the storage subsystem for Fibre Channel.
7. Verify the storage controller properties.
8. Configure the storagesets.
9. Install SANworks Secure Path software.
10. Connect the HBAs to the switches.
11. Set the storage controllers to multibus failover.
12. Select
PreferPrefer
PreferPrefer
Prefer for the storage unit paths.
13. Install Microsoft Cluster Service.
