Appendix A
Hardware Specifications
Table 2
10 T PCI UTP; 10 T/2 PCI UTP/Coax; 10/100 TX PCI UTP Controllers
Network Interface IEEE 802.3 (ISO/IEC 8802-3) CSMA/CD protocol
Bus Data Interface 32-bit PCI bus-mastering
Dimensions 5.3L x 2.7H, inches (13.5L x 6.9H, centimeters)
Power
10 T
10 T/2
10/100 TX
180mA @ +5V maximum
250mA @ +5V maximum; 135mA @ +12V maximum
614mA @ +5V maximum
Interrupts (IRQ) Supported Automatically allocated by system
Connectors and Cabling:
10 T and 10/100 TX
10 T/2
RJ-45, 8-pin; 10Mb/s: Category 3, 4, or 5 UTP cable 22-26AWG, 100Ω @
1MHz; 100Mb/s Category 5 UTP cable 22-26AWG, 100Ω @ 1MHz meeting
EIA/TIA 568A or EIA/TIA 568B
BNC with “T” connectors; RG58 A/U 50Ω; 50Ω terminator
Emissions and European
Community Classifications
FCC Class B; EN55022 Class B; Canadian Class B digital apparatus; VCCI
Class 1 and 2; CE-Compliant to both the EMC and Low Voltage Directives
Safety Classifications UL 1950 (ITE); CNL 950 (ITE); TUV EN60950:1992
Electromagnetic Immunity EN50082-1; IEC801-2 (ESD); IEC801-3 (Radiated Immunity); IEC801-4 (Fast
Transient Burst)
Temperature Range Operating: 0–55°C (32–131°F); Storage: -65–85°C (-85–185°F)
Humidity (non-condensing) Operating: 10% to 90%; Storage: 5% to 95%
