Maintenance and Service Guide

4-18 Replaceable Parts Service Manual
Part
Description
Exchange
Part
Number Description
Pavilion
ze5x00,
nx9010,
nx9008
and
Presario
2500
Pavilion
ze4x00,
nx9005,
Evo
N1050v
and
Presario
2100
Pavilion
ze4200,
nx9000
and
Presario
2100
Evo
N1010
v
and
Presari
o 1100
F5771J
Pavilion
ze4100
H5761H
User
Repl
19436-001 Display 14.1-inch XGA–
Pavilion KE
•
• •
No
319437-001 Display 15.0-inch XGA–
Pavilion KE
•
• •
No
319438-001 Display 15.0-inch SXGA+–
Pavilion KE
•
• •
No
319439-001 SPS-DSPLY PANEL 15.0-
inch SXGA CPQ
• •
No
319440-001 SPS-DSPLY PANEL 15.0-
inch XGA CPQ
• •
No
319441-001 SPS-DSPLY PANEL 14.1-
inch XGA CPQ
• •
No
319445-001
SPS-BD INVERTER
• •
No
319446-001
Kit, display screw cover
•
• •
Yes
319447-001 Speaker assy–F
• •
•
No
319448-001 FDD Assy w/cable–1F
• •
• •
No
319449-001
SPS-BD SYSTEM DF
•
No
319450-001
SPS-BD SYSTEM FF
•
No
319453-001
PCA, IR–1F w/IR
• •
• •
No
319454-001
PCA, IR–1F w/o IR
• •
• •
No
319455-001
Socket, PCMCIA–1F
• •
• •
No
319456-001
Heat sink–1F w/fan
• •
• •
No
319457-001
SPS-PROC P4 1.6 GHz
• •
No
319458-001
CPU, P4 1.8 GHz
Northwood uFCPGA
• •
•
No
319459-001
CPU, P4 1.9 GHz
Northwood uFCPGA
• •
•
No
319460-001
CPU, P4 2.0 GHz
Northwood uFCPGA
• •
•
No
319461-001
SPS-PROC P4 2. GHz
• •
No
319462-001
SPS-PROC P4 2.4 GHz
• •
No
319463-001
CPU, Cel-M 1.6 GHz
Northwood uFCPGA
• •
• •
No
319464-001
CPU, Cel-M 1.7 GHz
Northwood uFCPGA
• •
•
No
319465-001
CPU, Cel-M 1.8 GHz
Northwood uFCPGA
• •
• •
No
319466-001
SPS-PROC C/2.0 GHz
• •
No
319467-001
Antennas, Wireless R&L–1F
• • • •
No
319468-002
Card, Mini PCI-802.11B
worldwide
• • • • •
Yes
319468-051
Card, Mini PCI-802.11B
France
• • • •
Yes
319469-001
Base Enclosure FF
•
No
