1-20 Product Information Service Manual
Mass Storage
20- to 60-GB removable hard drive with Ultra-DMA 100 interface
1.44-MB floppy drive (certain models)
24x CD-ROM, 8x DVD, CD-RW, or CD-RW/DVD drive (or higher)
RAM
At least 128 MB SDRAM preinstalled
HP Pavilion ze5x00, ze4x00, HP Compaq nx9010, nx9008,
nx9005, Compaq Evo N1050v, Compaq Presario 2500, and
Compaq Presario 2100:
2 slots for PC2100 DDR-266 SDRAM modules
Up to 1 GB (1024 MB) SDRAM using 512 MB modules
Compaq Evo N1010v and Presario 1100:
2 slots for PC2100 DDR-266 SDRAM modules
Up to 512 MB SDRAM using 256 MB modules
Audio System
Stereo sound via 2 built-in speakers
3D-enhanced audio
Volume and mute buttons (certain models)
Headphone-out and microphone-in
Keyboard and
Pointing Device
87/88-key touch-type QWERTY keyboard with 101/102 key emulation. Embedded
numeric keypad.
12 function (Fn) keys
5 user-programmable One-Touch buttons
Touch pad with integrated scroll pad, on-off button and indicator
Left and right Select buttons
LAN
(certain models)
Ethernet 10Base-T (10 Mbps) and 100Base-TX (100 Mbps) support
Supports wake-on-LAN, fast IP, DMI, dRMON
MBA (Managed Boot Agent) support for PXE/BINL, NCP/IPX, DHCP
Wireless LAN
(certain models)
802.11b or 802.11g (54g)
