Service Manual Removal and Replacement 2-29
Removing the Floppy Drive
(Service Partners Only)
NOTE: This section applies only to HP Pavilion ze4x00, HP Compaq nx9005 and nx9000,
Compaq Evo Notebook N1050v and N1010v, and Compaq Presario 2100 and 1100 models.
Required Equipment
1 Phillips screwdriver
Removal Procedure
1. Unplug the AC adapter, if present, and remove the battery.
2. Remove these additional assemblies:
•
Hard disk drive (page 2-9)
• Keyboard cover (page 2-13)
• Keyboard (page 2-16)
• Switchboard PCA (page 2-19)
• Display assembly (page 2-23)
• Top case (page 2-26)
3. Remove the two M2.5×4.0mm screws (right side) that secure the hard disk drive guide to the
motherboard. (Note that the screws (left side) are missing. These screws were removed during
the top case removal procedure.)
4. Disconnect the motherboard cable.
5. Remove the two M2.5×4.0mm screws that secure the floppy drive to the motherboard.
6. Remove the floppy drive.
