Service Manual Removal and Replacement 2-39
NOTE: This section applies only to HP Pavilion 5x00, HP Compaq nx9010 and HP nx9008,
and Compaq Presario 2500 models.
Required Equipment
0 Phillips screwdriver
Removal Procedure
1. Unplug the AC adapter, if present, and then remove the battery.
2. Remove these additional assemblies:
•
Hard disk drive (page 2-9)
• Keyboard cover (page 2-13)
• Keyboard (page 2-16)
• Switchboard PCA (page 2-19)
• Display assembly (page 2-23)
• Top case (page 2-26)
