Service Manual Removal and Replacement 2-45
NOTE: This section applies only to HP Pavilion 5x00, HP Compaq nx9010 and nx9008,
and Compaq Presario 2500 models.
Removal Procedure
1. Unplug the AC adapter, if present, and then remove the battery.
2. Remove these additional assemblies:
•
Hard disk drive (page 2-9)
• Keyboard cover (page 2-13)
• Keyboard (page 2-16)
• Switchboard PCA (page 2-19)
• Display assembly (page 2-23)
• Top case (page 2-26)
• Heat sink (page 2-40)
