Introduction 11
CPQMAP
CPQMAP is a foreground process started by OVW that performs the following functions:
• Creates and updates node or subsystem map symbols for all HP nodes identified by the CPQDIS
process ("CPQDIS" on page 10)
• Replaces the default NNM subsystem symbols with specific symbols for HP server, client, and
storage systems and creates the Web status icons in the node submaps for all identified nodes
running HP Insight Management Agents
CPQWEB
CPQWEB is a foreground process that launches the default browser specified during the installation and
configuration of the Insight Integration.
This process is used to connect to the HP System Management Homepage of the web-enabled Insight
Management Agents on a selected node.
If the web-enabled Insight Management Agents are installed and running on a node, they will be
identified in the corresponding node submap by an executable icon labeled "Insight Agents." By selecting
this executable icon, the CPQWEB process will be invoked to launch the default browser, whose path
information is defined in the CPQWEB.CONF file.
NOTE: For best results, use only supported browser configurations. See "Recommended
browser support (on page 8)" for a list of tested browsers.
CPQRILOE
CPQRILOE is a foreground process used to launch the default browser specified during the installation
and configuration of the Insight Integration.
This process is used to connect to the RILOE, RILOE II, iLO, or iLO 2 remote management processor
features on HP ProLiant servers that have this capability installed. This connection enables administrators
to perform advanced remote management and administration of HP ProLiant servers.
If the server has a remote management processor installed and configured with HP Insight Management
Agents, it will be identified with the CPQRILOE field. Right-clicking the server enables you to launch to the
RILOE, RILOE II, iLO, or iLO 2 browser-based interface by selecting the Insight Lights-Out option.
NOTE: For best results, use only supported browser configurations. See "Recommended
browser support (on page 8)" for a list of tested browsers.
HPSIM
HPSIM is a foreground process used to launch the browser specified in the
$OV_CON/C/cpq/CpqWeb.conf file. This process is used to connect to the HP Systems Insight
Manager homepage from NNM.
