Introduction 12
HPSIMLNH
HPSIMLNH is a foreground process used to launch the browser specified in the
OV_CON/C/cpq/CpqWeb.conf file. This process is used to connect to HP Systems Insight Manager and
display the node selected in NNM.
Path names and components
The following table lists the absolute path names of the Insight Integration components.
Component Path name
Insight Integration executables $OV_BIN/CPQ
Application registration files (CPQINFOAPP.REG,
CPQMAPAPP.REG)
$OV_REGISTRATION/$LANG/CPQ
Symbol registration file (CPQSYM.REG) $OV_SYMBOLS/$LANG/CPQ
Field registration file (CPQFIELD.REG) $OV_FIELDS/$LANG/CPQ
Bitmaps $OV_BITMAPS/$LANG
Configuration files $OV_CONF/$LANG/CPQ
Local registration files $OV_LRF
Insight Integration tools $OV_MAIN_PATH/INSTALL/TOOLS/CPQ
Java™ interface icons $OV_WWW/
Java™ interface registration files $OV_WWW_REG/
Dynamic Views menu definition $OV_WWW_REG/dynamicviews/$LANG
The following table lists the directories and contents associated with the Insight Integration.
Directory Contents
/bin Binaries for the Insight Integration processes
/bitmaps Icons used by Insight Integration
/config The CPQCONFIG.DAT file for HP systems discovery and the CPQWEB.CONF
file for configuring default browser settings.
/docs Insight Integration for HP Network Node Manager Revision 3.4 User Guide
/dynamicViews Menu files for NNM Home Base
/fields Field registration files used by the Insight Integration
/hpqtraps Files needed for the event (trap) only installation of the Insight Integration
/hpsim Files for the HP Systems Insight Manager server
/ipf Support files for HP Integrity Superdome servers
/lrf Registration files for the CPQDIS and CPQTRAPD processes
/mibs ProLiant MIBs used by the Insight Integration
/registration Application and menu registration information
/symbols Updates to the symbol registration files
/tools Tools used to verify the installation
