Introduction 9
• Microsoft® Internet Explorer 6.0 or later
Operating system support
The following versions of HP-UX on HP 9000 series 700/800 systems support Insight Integration.
HP Network Node
Manager version
HP-UX 11.0 HP-UX 11.11 HP-UX 11.23
6.3x Yes Yes No
6.4x Yes Yes No
7.0x Yes Yes No
7.5 Yes Yes Yes
The following Microsoft® Windows® for Intel® systems support Insight Integration.
HP Network Node
Manager version
Windows® XP Windows® 2000 Windows Server™ 2003
6.3.1 No Yes No
6.4x Yes Yes No
7.0x Yes Yes No
7.5 Yes Yes Yes
The following Solaris (SPARC) versions support Insight Integration.
HP Network Node
Manager version
Solaris 8 Solaris 9
6.3x Yes No
6.4x Yes Yes
7.0x Yes Yes
7.5x Yes Yes
Product architecture
The Insight Integration performs the following functions:
• Automatically discovers and displays HP nodes running Insight Management Agents on the NNM
management map
• Populates HP hardware status to all NNM maps
• Identifies and records HP SNMP events in the NNM Event Log
• Translates and displays in the Event Browser all HP SNMP events for system hardware and related
services
