A Specifications
Table A-1 Specifications
Desktop Dimensions
Height
Width
Depth
3.95 in
13.3 in
14.9 in
10.0 cm
33.8 cm
37.8 cm
Approximate Weight 19 lb 8.6 kg
Weight Supported (maximum distributed load in desktop
position)
77 lb 35 kg
Temperature Range
Operating
Nonoperating
50° to 95°F
-22° to 140°F
10° to 35°C
-30° to 60°C
NOTE: Operating temperature is derated 1.0° C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level; no direct
sustained sunlight. Maximum rate of change is 10° C/Hr. The upper limit may be limited by the type and number of
options installed.
Relative Humidity (noncondensing)
Operating
Nonoperating (38.7°C max wet bulb)
10-90%
5-95%
10-90%
5-95%
Maximum Altitude (unpressurized)
Operating
Nonoperating
10,000 ft
30,000 ft
3048 m
9144 m
Heat Dissipation
Maximum (standard PS)
Typical (idle; standard PS)
Maximum (80 Plus PS)
Typical (idle; 80 Plus PS)
1260 BTU/hr
307 BTU/hr
1,024 BTU/hr
239 BTU/hr
318 kg-cal/hr
77 kg-cal/hr
258 kg-cal/hr
60 kg-cal/hr
Power Supply
Operating Voltage Range
1
Rated Voltage Range
Rated Line Frequency
115V
90-264 VAC
100-240 VAC
50-60 Hz
230V
90-264 VAC
100-240 VAC
50-60 Hz
Power Output 240 W 240 W
Rated Input Current (maximum)
1
46 Appendix A Specifications ENWW
