Bottom
Component Description
(1) Battery bay Holds the battery.
(2) Vents (5) Enable airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal for
the internal fan to cycle on and off during routine operation.
(3)
Battery release latch Releases the battery from the battery bay.
(4)
Service door Provides access to the hard drive, wireless modules, and
memory modules.
16 Chapter 2 External component identification
