Designator Silk screen Component
P27 DASH/USB1 DASH/Dual internal USB
P29 P29 HDD LED Hard disk drive LED connector
P54 COM Serial port header
P60-P64 SATA0 - SATA4 SATA connectors
P65 eSATA eSATA connector
P66 - P67 P66 - P67
SATA4 - SATA5
SATA connectors
P70 P70 CPU0 FAN Primary CPU fan header
P124 P124 HOOD LOCK Side access panel solenoid lock header
P126 PAR Parallel port header
XBT1 XBT1 BAT Battery holder
XMM1 - XMM4 XMM1 - XMM4
DIMM1 - DIMM4
Memory slots
XU1 XU1 Primary CPU socket
162 Appendix B System board designators ENWW
