Product diagnostics
Table D-4 Product diagnostics
Topic Location
Diagnostics tools The HP Vision Diagnostics utility can be found as a
burnable ISO image on the workstation hard disk (under C:
\VisionDiagnostics), or can be downloaded from the
HP web site. For details on using this utility, refer to the
section that covers HP Vision Diagnostics in the workstation
Maintenance and Service Guide.
Audible beep and LED code
definitions
Refer to the appropriate section of the workstation
Maintenance and Service Guide for detailed information
about beep and Light Emitting Diode (LED) codes
applicable to the workstation.
170 Appendix D Locating HP resources ENWW
