Table 4-1 Computer Setup (F10) Utility menu descriptions (continued)
Heading Option Description
Device Options Enable/disable the following device options:
●
S5 Wake-on-LAN (Enabled/Disabled)
●
Turbo Mode (Enabled/Disabled)
●
Printer Mode (EPP+ECP, Output Only, Bi-Directional).
●
Num Lock State at Power-On (On/Off)
● Integrated Video
1
(Enabled/Disabled)
●
IGD (Integrated Graphics Device) Memory—Displayed when Integrated Video is
Enabled. Sets the maximum amount of system memory that can be allocated as
graphics memory (32, 64 (default), 128, 256, 512 MB)
1
●
Internal Speaker (Enabled/Disabled)
●
NIC Option ROM
2
Download (PXE/Disabled)
●
SATA RAID Option ROM
2
Download (Enabled/Disabled)
●
Multi-Processor (Enabled/Disabled)
● Hyperthreading
1
(Disabled/Enabled)
Slot Settings Lets you Enable/Disable Option ROM Download for each slot. Selective disabling of Option
ROM downloads can help manage limited Option ROM space.
AMT
Configuration
Lets you set the following AMT (Intel Active Management Technology) configuration options:
●
AMT (Enabled/Disabled)—Allows for remote discovery, repair and protection of
networked workstations. Enabling the AMT function also enables the Network Controller
(required for AMT to function correctly).
● Unconfigure AMT/ME (Disabled/Enabled)
2
—Restores AMT/ME defaults. When you
save and exit after enabling this option, you will be prompted to complete the process
upon restart. A Setup Password (even if one is set) does not need to be entered to
complete the process.
NOTE: Information about Intel AMT can be found at www.intel.com.
●
WatchDog Timer (Enabled/Disabled)—OS and BIOS WatchDog Timers can be set
independently (in minutes):
◦
OS WatchDog Timer—Sets the OS WatchDog Timer
◦
BIOS WatchDog Timer—Sets the BIOS WatchDog Timer.
1
Available on selected models
2
These options should be used by advanced users only
ENWW
The Computer Setup (F10) Utility
35
